WO2007090748A1 - Benzamide and heteroarene derivatives - Google Patents
Benzamide and heteroarene derivatives Download PDFInfo
- Publication number
- WO2007090748A1 WO2007090748A1 PCT/EP2007/050811 EP2007050811W WO2007090748A1 WO 2007090748 A1 WO2007090748 A1 WO 2007090748A1 EP 2007050811 W EP2007050811 W EP 2007050811W WO 2007090748 A1 WO2007090748 A1 WO 2007090748A1
- Authority
- WO
- WIPO (PCT)
- Prior art keywords
- alkyl
- halo
- hydrogen
- halogen
- alkoxy
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Ceased
Links
Classifications
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07C—ACYCLIC OR CARBOCYCLIC COMPOUNDS
- C07C233/00—Carboxylic acid amides
- C07C233/64—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings
- C07C233/66—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings having the nitrogen atom of at least one of the carboxamide groups bound to a carbon atom of a hydrocarbon radical substituted by halogen atoms or by nitro or nitroso groups
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61K—PREPARATIONS FOR MEDICAL, DENTAL OR TOILETRY PURPOSES
- A61K31/00—Medicinal preparations containing organic active ingredients
- A61K31/16—Amides, e.g. hydroxamic acids
- A61K31/165—Amides, e.g. hydroxamic acids having aromatic rings, e.g. colchicine, atenolol, progabide
- A61K31/166—Amides, e.g. hydroxamic acids having aromatic rings, e.g. colchicine, atenolol, progabide having the carbon of a carboxamide group directly attached to the aromatic ring, e.g. procainamide, procarbazine, metoclopramide, labetalol
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61K—PREPARATIONS FOR MEDICAL, DENTAL OR TOILETRY PURPOSES
- A61K31/00—Medicinal preparations containing organic active ingredients
- A61K31/33—Heterocyclic compounds
- A61K31/395—Heterocyclic compounds having nitrogen as a ring hetero atom, e.g. guanethidine or rifamycins
- A61K31/435—Heterocyclic compounds having nitrogen as a ring hetero atom, e.g. guanethidine or rifamycins having six-membered rings with one nitrogen as the only ring hetero atom
- A61K31/44—Non condensed pyridines; Hydrogenated derivatives thereof
- A61K31/4402—Non condensed pyridines; Hydrogenated derivatives thereof only substituted in position 2, e.g. pheniramine, bisacodyl
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P3/00—Drugs for disorders of the metabolism
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P3/00—Drugs for disorders of the metabolism
- A61P3/04—Anorexiants; Antiobesity agents
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P3/00—Drugs for disorders of the metabolism
- A61P3/06—Antihyperlipidemics
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P3/00—Drugs for disorders of the metabolism
- A61P3/08—Drugs for disorders of the metabolism for glucose homeostasis
- A61P3/10—Drugs for disorders of the metabolism for glucose homeostasis for hyperglycaemia, e.g. antidiabetics
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P43/00—Drugs for specific purposes, not provided for in groups A61P1/00-A61P41/00
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P9/00—Drugs for disorders of the cardiovascular system
- A61P9/04—Inotropic agents, i.e. stimulants of cardiac contraction; Drugs for heart failure
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P9/00—Drugs for disorders of the cardiovascular system
- A61P9/10—Drugs for disorders of the cardiovascular system for treating ischaemic or atherosclerotic diseases, e.g. antianginal drugs, coronary vasodilators, drugs for myocardial infarction, retinopathy, cerebrovascula insufficiency, renal arteriosclerosis
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P9/00—Drugs for disorders of the cardiovascular system
- A61P9/12—Antihypertensives
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07C—ACYCLIC OR CARBOCYCLIC COMPOUNDS
- C07C233/00—Carboxylic acid amides
- C07C233/64—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings
- C07C233/65—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings having the nitrogen atoms of the carboxamide groups bound to hydrogen atoms or to carbon atoms of unsubstituted hydrocarbon radicals
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07C—ACYCLIC OR CARBOCYCLIC COMPOUNDS
- C07C233/00—Carboxylic acid amides
- C07C233/64—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings
- C07C233/67—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings having the nitrogen atom of at least one of the carboxamide groups bound to a carbon atom of a hydrocarbon radical substituted by singly-bound oxygen atoms
- C07C233/68—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings having the nitrogen atom of at least one of the carboxamide groups bound to a carbon atom of a hydrocarbon radical substituted by singly-bound oxygen atoms with the substituted hydrocarbon radical bound to the nitrogen atom of the carboxamide group by an acyclic carbon atom
- C07C233/73—Carboxylic acid amides having carbon atoms of carboxamide groups bound to carbon atoms of six-membered aromatic rings having the nitrogen atom of at least one of the carboxamide groups bound to a carbon atom of a hydrocarbon radical substituted by singly-bound oxygen atoms with the substituted hydrocarbon radical bound to the nitrogen atom of the carboxamide group by an acyclic carbon atom of a carbon skeleton containing six-membered aromatic rings
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07D—HETEROCYCLIC COMPOUNDS
- C07D213/00—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members
- C07D213/02—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members
- C07D213/04—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom
- C07D213/24—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom with substituted hydrocarbon radicals attached to ring carbon atoms
- C07D213/36—Radicals substituted by singly-bound nitrogen atoms
- C07D213/40—Acylated substituent nitrogen atom
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07D—HETEROCYCLIC COMPOUNDS
- C07D213/00—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members
- C07D213/02—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members
- C07D213/04—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom
- C07D213/60—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom with hetero atoms or with carbon atoms having three bonds to hetero atoms with at the most one bond to halogen, e.g. ester or nitrile radicals, directly attached to ring carbon atoms
- C07D213/61—Halogen atoms or nitro radicals
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07D—HETEROCYCLIC COMPOUNDS
- C07D213/00—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members
- C07D213/02—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members
- C07D213/04—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom
- C07D213/60—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom with hetero atoms or with carbon atoms having three bonds to hetero atoms with at the most one bond to halogen, e.g. ester or nitrile radicals, directly attached to ring carbon atoms
- C07D213/78—Carbon atoms having three bonds to hetero atoms, with at the most one bond to halogen, e.g. ester or nitrile radicals
- C07D213/81—Amides; Imides
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07D—HETEROCYCLIC COMPOUNDS
- C07D213/00—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members
- C07D213/02—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members
- C07D213/04—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom
- C07D213/60—Heterocyclic compounds containing six-membered rings, not condensed with other rings, with one nitrogen atom as the only ring hetero atom and three or more double bonds between ring members or between ring members and non-ring members having three double bonds between ring members or between ring members and non-ring members having no bond between the ring nitrogen atom and a non-ring member or having only hydrogen or carbon atoms directly attached to the ring nitrogen atom with hetero atoms or with carbon atoms having three bonds to hetero atoms with at the most one bond to halogen, e.g. ester or nitrile radicals, directly attached to ring carbon atoms
- C07D213/78—Carbon atoms having three bonds to hetero atoms, with at the most one bond to halogen, e.g. ester or nitrile radicals
- C07D213/81—Amides; Imides
- C07D213/82—Amides; Imides in position 3
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07D—HETEROCYCLIC COMPOUNDS
- C07D231/00—Heterocyclic compounds containing 1,2-diazole or hydrogenated 1,2-diazole rings
- C07D231/02—Heterocyclic compounds containing 1,2-diazole or hydrogenated 1,2-diazole rings not condensed with other rings
- C07D231/10—Heterocyclic compounds containing 1,2-diazole or hydrogenated 1,2-diazole rings not condensed with other rings having two or three double bonds between ring members or between ring members and non-ring members
- C07D231/14—Heterocyclic compounds containing 1,2-diazole or hydrogenated 1,2-diazole rings not condensed with other rings having two or three double bonds between ring members or between ring members and non-ring members with hetero atoms or with carbon atoms having three bonds to hetero atoms with at the most one bond to halogen, e.g. ester or nitrile radicals, directly attached to ring carbon atoms
- C07D231/16—Halogen atoms or nitro radicals
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07D—HETEROCYCLIC COMPOUNDS
- C07D239/00—Heterocyclic compounds containing 1,3-diazine or hydrogenated 1,3-diazine rings
- C07D239/02—Heterocyclic compounds containing 1,3-diazine or hydrogenated 1,3-diazine rings not condensed with other rings
- C07D239/24—Heterocyclic compounds containing 1,3-diazine or hydrogenated 1,3-diazine rings not condensed with other rings having three or more double bonds between ring members or between ring members and non-ring members
- C07D239/28—Heterocyclic compounds containing 1,3-diazine or hydrogenated 1,3-diazine rings not condensed with other rings having three or more double bonds between ring members or between ring members and non-ring members with hetero atoms or with carbon atoms having three bonds to hetero atoms with at the most one bond to halogen, directly attached to ring carbon atoms
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07F—ACYCLIC, CARBOCYCLIC OR HETEROCYCLIC COMPOUNDS CONTAINING ELEMENTS OTHER THAN CARBON, HYDROGEN, HALOGEN, OXYGEN, NITROGEN, SULFUR, SELENIUM OR TELLURIUM
- C07F7/00—Compounds containing elements of Groups 4 or 14 of the Periodic Table
- C07F7/02—Silicon compounds
- C07F7/08—Compounds having one or more C—Si linkages
- C07F7/0803—Compounds with Si-C or Si-Si linkages
- C07F7/081—Compounds with Si-C or Si-Si linkages comprising at least one atom selected from the elements N, O, halogen, S, Se or Te
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07C—ACYCLIC OR CARBOCYCLIC COMPOUNDS
- C07C2601/00—Systems containing only non-condensed rings
- C07C2601/02—Systems containing only non-condensed rings with a three-membered ring
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07C—ACYCLIC OR CARBOCYCLIC COMPOUNDS
- C07C2601/00—Systems containing only non-condensed rings
- C07C2601/04—Systems containing only non-condensed rings with a four-membered ring
Definitions
- the present invention relates to novel benzamide and heteroarene carboxamide derivatives, processes for their preparation, their use as pharmaceuticals and to pharmaceutical compositions comprising them.
- the present invention provides in a first aspect a compound of formula I
- R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C ⁇ alkylsilyl;
- R 2 is hydrogen or a group
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 - cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 . cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- X is CR 12 or N
- Y is CH or N; wherein X and Y are not N at the same time;
- R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo- Ci-C 6 alkoxy;
- R 5 is hydrogen, Q-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy R 4 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- R 3 is hydrogen, Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-Q-Ce. alkoxy;
- R 10 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R » 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- Ci-C ⁇ alkyl examples include branched and straight-chain monovalent saturated aliphatic hydrocarbon radicals of one to six carbon atoms, e.g. methyl, ethyl, propyl, isopropyl, butyl, isobutyl, tert. -butyl, the isomeric pentyls and the isomeric hexyls.
- halogen examples include fluorine, chlorine, bromine and iodine.
- halo-Ci-C ⁇ alkyl examples include Ci-C ⁇ alkyl groups as defined above wherein at least one of the hydrogen atoms of the Ci-C ⁇ alkyl group is replaced by a halogen atom, e.g. fluoro or chloro, e.g. trifluoromethyl, difluoromethyl, fluoromethyl, 1, 2,2,2- tetrafluoro-1- trifluoromethyl-ethyl, pentafluoroethyl and chlorodifluoromethyl.
- a halogen atom e.g. fluoro or chloro
- trifluoromethyl difluoromethyl
- fluoromethyl 1, 2,2,2- tetrafluoro-1- trifluoromethyl-ethyl
- pentafluoroethyl pentafluoroethyl and chlorodifluoromethyl.
- halo-Ci-C ⁇ alkoxy examples include alkoxy groups of formula O-Ci-C ⁇ alkyl wherein at least one of the hydrogen atoms of the alkoxy group is replaced by a halogen atom, e.g. fluoro or chloro, e.g. trifluoromethoxy, difluoromethoxy, fluoromethoxy and chloro- difluoromethoxy.
- halogen atom e.g. fluoro or chloro
- Cs-Cscycloalkyl examples include saturated carbocyclic groups containing from 3 to 8 carbon atoms, such as cyclopropyl, cyclobutyl, cyclopentyl, cyclohexyl, cycloheptyl and cyclooctyl.
- halo-Cs-Cscycloalkyl examples include 1-fluorocyclobutyl.
- tri-Ci-C ⁇ alkylsilyl examples include trimethylsilyl.
- salts refers to those salts which retain the biological effectiveness and properties of the free bases or free acids, which are not biologically or otherwise undesirable.
- the salts are formed with inorganic acids such as hydrochloric acid, hydrobromic acid, sulfuric acid, nitric acid, phosphoric acid and the like, preferably hydro- chloric acid, and organic acids such as acetic acid, propionic acid, glycolic acid, pyruvic acid, oxylic acid, maleic acid, malonic acid, salicylic acid, succinic acid, fumaric acid, tartaric acid, citric acid, benzoic acid, cinnamic acid, mandelic acid, methanesulfonic acid, ethanesulfonic acid, p-toluenesulfonic acid, salicylic acid, N-acetylcystein and the like.
- salts derived from an inorganic base include, but are not limited to, the sodium, potassium, lithium, ammonium, calcium, magnesium salts and the like.
- Salts derived from organic bases include, but are not limited to salts of primary, secondary, and tertiary amines, substituted amines including naturally occurring substituted amines, cyclic amines and basic ion exchange resins, such as isopropylamine, trimethylamine, diethyl- amine, triethylamine, tripropylamine, ethanolamine, lysine, arginine, N-ethylpiperidine, piperidine, polymine resins and the like.
- the compound of formula I can also be present in the form of zwitterions. Particularly preferred pharmaceutically acceptable salts of compounds of formula I are the hydrochloride salts.
- the compounds of formula I can also be solvated, e.g. hydrated.
- the solvation can be effected in the course of the manufacturing process or can take place e.g. as a consequence of hygroscopic properties of an initially anhydrous compound of formula I (hydration).
- pharmaceutically acceptable salts also includes physiologically acceptable solvates.
- “Isomers” are compounds that have identical molecular formulae but that differ in the nature or the sequence of bonding of their atoms or in the arrangement of their atoms in space. Isomers that differ in the arrangement of their atoms in space are termed “stereoisomers”. Stereoisomers that are not mirror images of one another are termed “diastereo- isomers”, and stereoisomers that are non-superimposable mirror images are termed “enan- tiomers”, or sometimes optical isomers. A carbon atom bonded to four nonidentical sub- stituents is termed a "chiral center”.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cycloalkyl or tri-Ci-C 6 alkylsilyl.
- R 1 is Ci-C ⁇ alkyl.
- the present invention provides a compound of formula I wherein R 1 is butyl.
- the present invention provides a compound of formula I wherein R 1 is tert-butyl.
- the present invention provides a compound of formula I wherein R 2 is hydrogen.
- the present invention provides a compound of formula I wherein R 2 is a group (a). In another embodiment the present invention provides a compound of formula I wherein R 2 is a group (a) wherein R 6 and R 7 are independently halo-Ci-C ⁇ alkyl or halogen. In still another embodiment the present invention provides a compound of formula I wherein R 2 is a group (a) wherein R 6 halo-Ci-C ⁇ alkyl and R 7 is halogen. In still another embodiment the present invention provides a compound of formula I wherein R 2 is a group (a) wherein R 6 is CF 3 and R 7 is Cl.
- the present invention provides a compound of formula I wherein R 2 is a group (b).
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein R 8 and R 9 are independently hydrogen, halo- Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl or halo-Ci-C ⁇ alkoxy.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein R 8 and R 9 are independently hydrogen, CF 3 , Cl, F, cyclopropyl or OCF 3 .
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein R 8 is hydrogen, CF 3 , Cl, F, cyclopropyl or OCF 3 .
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl or halo-Ci-C ⁇ alkoxy.
- the present invention provides a com- pound of formula I wherein R 2 is a group (b) wherein R 8 and R 9 are independently hydrogen, CH 2 CH 3 , (CHi) 2 CH 3 , CH(CH 3 ) 2 , CF 3 , Br, Cl, F, cyclopropyl or OCF 3 .
- R 8 is hydrogen, CH 2 CH 3 , (CH 2 ) 2 CH 3 , CH(CH 3 ) 2 , CF 3 , Br, Cl, F, cyclo- propyl or OCF 3 .
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein R 9 is hydrogen, Cl or F. In still another embodiment the present invention provides a compound of formula I wherein R 2 is a group (b) wherein R 9 is hydrogen or F.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 .
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen or halo-Ci-C ⁇ alkoxy.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl or halogen.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen or halogen. In still another embodiment the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, Cl or F. In still another embodiment the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl or halo-Ci-C ⁇ alkoxy.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen or Cs-Cscycloalkyl.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, halogen or Cs-Cscycloalkyl.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is CR 12 wherein R 12 is hydrogen, Cl, F or cyclopropyl.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein X is or N and Y is CH.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein Y is CH.
- the present invention provides a compound of formula I wherein R 2 is a group (b) wherein Y is N and X is CR 12 .
- the present invention provides a compound of formula I wherein A is CR 10 .
- the present invention provides a compound of formula I wherein A is CR 10 wherein R 10 is hydrogen, or is halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl or OH, when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein A is CR 10 wherein R 10 is halo-Ci-C 6 alkyl or halogen, when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein A is CR 10 wherein R 10 is CF 3 or Cl, when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein A is N and B and D are not N.
- the present invention provides a compound of formula I wherein B is CR 11 .
- the present invention provides a compound of formula I wherein B is CR 11 wherein R 11 is hydrogen or is halogen, when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen.
- the present invention provides a compound of formula I wherein B is CR 11 wherein R 11 is hydrogen or is F or Cl, when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen.
- the present inven- tion provides a compound of formula I wherein B is CR 11 wherein R 11 is hydrogen.
- the present invention provides a compound of formula I wherein B is N and A is not N.
- the present invention provides a compound of formula I wherein D is CR 3 . In still another embodiment the present invention provides a compound of formula I wherein D is CR 3 wherein R 3 is hydrogen.
- the present invention provides a compound of formula I wherein D is N.
- the present invention provides a compound of formula I wherein R 5 is hydrogen, halo-Ci-C ⁇ alkyl, halogen or OH. In still another embodiment the present invention provides a compound of formula I wherein R 5 is hydrogen, halo-Ci-C ⁇ alkyl or halogen. In still another embodiment the present invention provides a compound of formula I wherein R 5 is hydrogen or halogen. In still another embodiment the present invention provides a compound of formula I wherein R 5 is hydrogen or F.
- the present invention provides a compound of formula I wherein R 4 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl or halogen when at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein R 4 is halo-Ci-C ⁇ alkyl or halogen and at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein R 4 is CF 3 or Cl and at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein R 4 is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl or halogen and at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen.
- the present invention provides a compound of formula I wherein R 4 is CH 2 CH 3 , CF 3 or Cl and at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen.
- the present invention provides compounds of formula I wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen.
- the present invention provides a compound of formula I wherein n is 1.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C 6 alkylsilyl;
- R 2 is hydrogen;
- R 5 is hydrogen, Q-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
- R -.4 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C ⁇ alkoxy when at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen;
- A is CR 10 or N
- B is CR 11 or N
- R 10 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R » 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C 6 alkoxy, when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C ⁇ alkylsilyl; R 2 is a group
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- R 5 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- R 3 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R ) 11 is hydrogen or is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo- Ci-C ⁇ alkoxy, when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C 6 alkylsilyl; R 2 is a group wherein
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 - cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- X is CR 12 or N;
- Y is CH or N; wherein X and Y are not N at the same time;
- R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R ) 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C 6 alkylsilyl;
- R 2 is hydrogen or a group wherein
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -Cs- cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -Cs- cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- X is CR 12 or N;
- Y is CH or N; wherein X and Y are not N at the same time;
- R 12 is hydrogen, Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, Q-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
- R -.4 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Q-Cscycloalkyl, OH or halo- Ci-C ⁇ alkoxy when at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen;
- A is CR 10 ;
- B is CR 11 or N
- D is CR 3 or N
- R 3 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C 6 alkoxy;
- R 10 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C ⁇ alkoxy, when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C ⁇ alkylsilyl; R 2 is hydrogen or a group
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 - cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 - cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- X is CR 12 or N;
- Y is CH or N; wherein X and Y are not N at the same time;
- R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, Q-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy R 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C 6 alkylsilyl;
- R 2 is hydrogen or a group wherein
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 - cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -C 8 - cycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- X is CR 12 or N;
- Y is CH or N; wherein X and Y are not N at the same time;
- R 12 is hydrogen, Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halogen, C 3 -C 8 cycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy is hydrogen, Q-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
- R -.4 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C ⁇ alkoxy when at least one of R 3 , R 5 , R 10 and R 11 is not hydrogen;
- A is CR 10 ;
- B is CR 11 or N
- D is CR 3 ;
- R 3 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-Ci- C 6 alkoxy;
- R 10 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C ⁇ alkoxy, when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl; R 2 is a group wherein
- R 8 and R 9 are independently hydrogen, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl or halo-Ci-C ⁇ alkoxy;
- X is CR 12 ;
- Y is CH
- R 12 is hydrogen or halogen
- R 5 is hydrogen or halogen
- R 4 is h alo - C i - C ⁇ alkyl or h alo gen
- A is CR 10 ;
- R 10 is halo-Ci-C 6 alkyl or halogen; R 11 is hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- the present invention provides a compound of formula I wherein R 1 is Ci-C 6 alkyl; R 2 is a group
- R 8 and R 9 are independently hydrogen, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl or halo-Ci-C ⁇ alkoxy;
- R 12 is hydrogen, halogen or Cs-Cscycloalkyl;
- R 5 is hydrogen or halogen;
- R 4 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl or halogen;
- A is CR 10 ;
- B is CR 11 or N;
- D is CR 3 ;
- R 3 is hydrogen;
- R 10 is halo-Ci-C 6 alkyl or halogen; R 11 is hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
- R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -C 8 cyclo- alkyl or tri-Ci-C ⁇ alkylsilyl;
- R 2 is hydrogen or a group
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -
- R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- R 3 and R 5 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 - Cecycloalkyl, OH or halo-Ci-C ⁇ alkoxy;
- R 4 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- R 10 is hydrogen, or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy when at least one of R 3 , R 4 , R 5 and R 11 is not hydrogen;
- R 11 is hydrogen or is Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C ⁇ alkoxy, when at least two of R 3 , R 4 , R 5 and R 10 are not hydrogen; wherein at least two of R 3 , R 4 , R 5 , R 10 and R 11 are not hydrogen; and n is 1, 2 or 3; which process comprises reacting an acid derivative, a compound of formula II
- R 4 , R 5 , A, B and D have the above meanings and W is hydroxy, 0Ii, ONa, OK or halogen, e.g. Cl, with a secondary amine derivative, a compound of formula III
- R 1 , R 2 and n have the above meanings.
- standard peptide coupling reagents can be applied to activate the acid prior to the coupling reaction.
- a coupling reagent such as EDC or EDC HCl, DCC, HBTU or TBTU in an inert solvent such as N,N-dimethylformamide, dimethylacetamide (DMA) or dichloromethane (DCM) together with the appropriate secondary amine derivative III.
- a base e.g.
- iV,iV-diisopropylethyl amine, triethylamine, iV-methyl morpholine) and/or 1- hydroxybenzotriazole (HOBT) can be added.
- the reaction mixture is stirred for 1 to 24 h at a temperature of about -3O 0 C to about 7O 0 C (e.g. ambient temperature).
- Acid derivatives of formula II are commercially available or can be prepared as described in the example section.
- Secondary amines of the general formula III can be synthesized by standard methods. They may be synthesized as outlined below.
- R 1 is Ci-C 6 alkyl, halo-Ci-C 6 alkyl, halo-Ci-C 6 alkoxy, C 3 -C 8 cycloalkyl, halo-C 3 -
- R 2 is hydrogen or a group
- R 6 and R 7 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -
- R 8 and R 9 are independently hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, C 3 -
- X i iss CCRR 1122 oorr NN;
- Y is CH or N; wherein X and Y are not N at the same time;
- R 12 is hydrogen, Ci-C ⁇ alkyl, halo-Ci-C ⁇ alkyl, halogen, Cs-Cscycloalkyl, OH or halo-
- Ci-C ⁇ alkoxy may be prepared by reductive amination of a benzaldehyde derivative, a compound of formula IV
- R 1 is as defined above, with an amine, a compound of formula V
- R and n are as defined above.
- the necessary starting amines and aldehydes are commercially available or are synthesized using standard methods as e.g. described in the example section.
- Secondary amines III may alternatively be synthesized from amide derivatives, compounds of formula VII
- R 1 , R 2 and n are as defined above.
- RT room temperature
- THF tetrahydrofuran
- DMF N,N-dimethylformamide
- DCM dichloromethane
- Lithium borohydride (2.16g, 99 mmol) was suspended in THF (50ml). Trimethylchloro- silane (21.6g, 198mmol) was added dropwise. A solution of l-chloro-2-fluoro-4-(2-nitro- vinyl) -benzene (5.Og, 24.8mmol) in THF (20ml) was added dropwise. Strong gas evolution and foam formation was observed. The white suspension was stirred at RT for 3 days. Carefully MeOH (80ml) was added. The solvents were removed in vacuo and the residue was purified by flash column chromatography (CH 2 Cl 2 / MeOH+5%aq.
- Example S4-B Preparation of 2-(3-bromo-4-chlorophenyl)-ethylamine: a) Preparation of (3-bromo-4-chlorophenyl)-acetonitrile:
- Example S5-C Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-trifluoromethylpyr- azol-1-yl) -ethyl] -amine and (4-?e/t-butylbenzyl)-[2-(4-chloro-5-tri- fluoromethylpyrazol-l-yl)-ethyl]-amine
- reaction mixture was stirred at O 0 C for 30 min and then 3-(4-t ⁇ t-butylbenzyl)- [ 1,2,3] oxathiazolidine 2,2-dioxide (300 mg, 1.11 mmol) was added portion wise.
- the reaction mixture was warmed to RT and stirred for a further 3h after which the reaction mixture was quenched with 5ml 20% (v/v) H 2 SO 4 .
- the reaction mixture was warmed to 6O 0 C overnight and then cooled to RT and poured into water.
- the aqueous phase was made basic with IN NaOH and then extracted with ethyl acetate.
- Example SIl-C Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-cyclopropylphenyl)- ethyl] -amine and (4-?e/t-butylbenzyl)-[2-(3,4-dicyclopropylphenyl)- ethyl] -amine
- step a example S8-C
- [2-(3-bromo-4-chlorophenyl)-ethyi]-(4-t ⁇ t-butylbenzyl)- amine 128 mg, 0.34 mmol
- cyclopropyl boronic acid 72 mg, 0.84 mmol
- reaction mixture was then left to warm slowly to RT ( 1 hour) and treated carefully with 2 ml water.
- the reaction mixture was then concentrated in vacuo, diluted with water and extracted with diethyl- ether.
- the aqueous phase was then acidified with concentrated HCl and extrated twice with ethylacetate.
- Example S5-D Preparation of 6-Methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid a) Preparation of 6-methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid ethyl ester: 2.241 g (20 mmol) of 2,2,2- trifluoro-acetamidine were dissolved in 80 ml ethanol and treated with 3.163 g (20 mmol) of 2,4-dioxo-pentanoic acid ethyl ester. The resulting solution was cooled to 0-5 0 C and treated with 120 ml of HCl- saturated ethanol. The reaction mixture was allowed to warm-up to RT and stirred for additional 3 hours.
- the compounds of formula I are cholesteryl ester transfer protein (CETP) inhibitors.
- Atherosclerosis and its associated coronary heart disease is the leading cause of death in the industrialized world. Risk for development of coronary heart disease has been shown to be strongly correlated with certain plasma lipid levels. Lipids are transported in the blood by lipoproteins. The general structure of lipoproteins is a core of neutral lipids (triglyceride and cholesterol ester) and an envelope of polar lipids (phospholipids and non esterified cholesterol).
- LDL low density lipoprotein
- HDL high density lipoprotein
- VLDL very low density lipoprotein
- TG triglyceride
- LDL-cholesterol (LDL-C) and triglyceride levels are positively correlated, while high levels of HDL-cholesterol (HDL-C) are negatively correlated with the risk for developing cardiovascular diseases.
- Plasma lipoprotein metabolism can be described as a flux of cholesterol between liver and the other tissues.
- the LDL pathway corresponds to the secretion of VLDL from the liver to deliver cholesterol by LDL to tissues. Any alteration in LDL catabolism could lead to uptake of excess cholesterol in the vessel wall forming foam cells and atherosclerosis.
- the opposite pathway is the mobilization of free cholesterol from peripheral tissues by HDL to deliver cholesterol to the liver to be eventually excreted with bile.
- cholesteryl ester CE
- cholesteryl ester transfer protein CETP
- CETP inhibitors are useful as medicaments for the treatment and/or prophylaxis of atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbeta-lipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myo- cardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
- CETP inhibitors maybe used in combination with another compound, said compound being an HMG-CoA reductase inhibitor, a microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion- exchange resin, an antioxidant, an ACAT inhibitor or a bile acid sequestrant.
- MTP microsomal triglyceride transfer protein
- the compounds of formula I of the present invention can be used as medicaments for the treatment and/or prophylaxis of diseases which are mediated by CETP.
- diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
- the use as medicament for the treatment and/or prevention of dyslipidemia is preferred.
- the invention therefore also relates to pharmaceutical compositions comprising a compound as defined above and a pharmaceutically acceptable carrier and/or adjuvant.
- the invention relates to compounds as defined above for use as therapeutically active substances, particularly as therapeutic active substances for the treatment and/or prophylaxis of diseases which are mediated by CETP.
- diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
- the invention relates to a method for the treatment and/or prophylaxis of diseases which are mediated by CETP.
- diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypo- alphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
- a method for the treatment and/or prophy- laxis of dyslipidemia is preferred.
- the invention further relates to the use of compounds of formula I as defined above for the treatment and/or prophylaxis of diseases are mediated by CETP.
- diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
- the use of compounds of formula I as defined above for the treatment and/or prophylaxis of dyslipidemia is preferred.
- the invention relates to the use of compounds of formula I as defined above for the preparation of medicaments for the treatment and/or prophylaxis of diseases are mediated by CETP.
- diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular dis- orders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
- the use of compounds of formula I as defined above for the preparation of medicaments for the treatment and/or prophylaxis of dyslipidemia is preferred.
- CETP inhibitors are useful in combination with another compound, said compound being an HMG-CoA reductase inhibitor, an microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion- exchange resin, an antioxidant, an ACAT inhibitor or a bile acid sequestrant.
- MTP microsomal triglyceride transfer protein
- the invention therefore also relates to pharmaceutical compositions comprising a com- pound of formula I as defined above in combination with an HMG-CoA reductase inhibitor, an microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion-exchange resin, an antioxidant, an ACAT inhi- bitor or a bile acid sequestrant, as well as a pharmaceutically acceptable carrier and/or adjuvant.
- MTP microsomal triglyceride transfer protein
- PPAR activator e acid reuptake inhibitor
- a cholesterol absorption inhibitor a cholesterol synthesis inhibitor
- fibrate niacin
- an ion-exchange resin an antioxidant
- an ACAT inhi- bitor or a bile acid sequestrant as well as a pharmaceutically acceptable
- the invention further relates to the use of compounds of formula I as defined above in combination with an HMG-CoA reductase inhibitor, a microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion- exchange resin, an antioxidant, an ACAT inhibitor or a bile acid sequestrant for the treatment and/or prophylaxis of diseases such as atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia, as well
- the compounds of formula I and their pharmaceutically acceptable salts possess valuable pharmacological properties. Specifically, it has been found that the compounds of the present invention are inhibitors of the cholesteryl ester transfer protein (CETP).
- CETP cholesteryl ester transfer protein
- CETP inhibitors Activity of CETP inhibitors was determined using a buffer assay system. Partially purified CETP transferred radiolabeled cholesteryl ester from HDL donor particles to biotin-labeled LDL acceptor particles. The reaction was stopped by addition of streptavidin-coupled scintillation proximity assay (SPA) beads. These beads captured the biotinylated acceptor particles and transferred radioactivity was measured. The assay system was purchased and per- formed according to manufacturer's recommendations (Amersham Biosciences). Inhibitory activity of compounds was determined as percentage of positive control activity containing CETP together with donor and acceptor particles. Serial dilution of compounds was performed in order to determine the IC 50 values.
- SPA streptavidin-coupled scintillation proximity assay
- Activity of the compounds was subsequently measured in the presence of plasma using the same assay as described above except that the source of CETP was human lipoprotein- deprived serum (LPDS). Inhibitory activity of compounds was determined as percentage of positive control activity containing all the assay components except compound. Serial dilution of compounds was performed in order to determine the IC 50 values.
- LPDS human lipoprotein- deprived serum
- the compounds of the present invention exhibit IC 50 values within the range of about 1 nM to about 100 ⁇ M, e.g., of about 1 nM to about 1 ⁇ M, e.g., of about 1 nM to about 200 nM.
- the following table shows measured values for some selected compounds of the present invention.
- In vivo activity of the compounds of formula I were determined in hamster using the following protocol: Male golden Syrian hamsters (6- week-old, 100- 130 g) under standard chow diet received compounds in the morning by oral gavage using appropriate vehicle, blood was taken 2 h later by retro-orbital bleeding under isofluran anaesthesia and 7 h later on sacrificed animals. Plasma was separated from blood using low speed centrifugation and CETP activity was measured in plasma using the radioactive CETP activity assay as described above except that diluted plasma replaced LPDS. In vivo CETP inhibition was expressed as CETP activity remaining in the plasma of treated animals as compared to plasma CETP activity of placebo treated animals.
- Efficacy of compounds in modulating plasma lipid levels can be determined in hamsters after 7 days of daily administration of compounds.
- Male hamsters are acclimated for 3-4 days to receive food as a paste made of 10 g chow and 10 g water per day.
- Compounds are then mixed within this paste and a portion containing the proper amount of compounds is given every morning for 7 days.
- compounds can be given by oral gavage using the proper vehicle.
- Blood is taken before compound treatment by retro-orbital bleeding and at the end of the treatment on sacrificed animals. Plasma is separated from blood by low speed centrifugation and selected organs are taken (e.g liver, fat, brain, etc.).
- Effects of compounds on plasma lipid levels are determined by measuring total cholesterol, HDL- cholesterol, LDL-cholesterol and triglyceride using colorimetric enzymatic assays (Roche Diagnostic GmbH, Mannheim, Germany).
- HDL-C, LDL-C and VLDL-C are e.g., quanti- fied using size exclusion chromatography on superpose-6 column using SMARTTM system (Pharmacia).
- Lipoprotein distribution is calculated assuming a Gaussian distribution for each peak, using a non-linear, least-squares curve-fitting procedure to calculate the area under the curve.
- Plasma samples are also used to quantify CETP activity as described above.
- Compound concentration is also determined in plasma and selected tissues as liver, fat, heart, muscle and brain.
- Efficacy of compounds in modulating plasma lipid levels was also determined in cholesterol/fat fed hamsters.
- the protocol is identical as described above except that animals are fed with chow diet enriched with 10 % (w/w) saturated fat and 0.05 % (w/w) cholesterol. Animals received this high fat diet 2 weeks before starting compound administration and continued this diet throughout the study. The 2 weeks pre-treatment induced an increase in plasma cholesterol and triglyceride levels allowing a better assessment of LDL-C and triglyceride lowering.
- Efficacy of compounds in its ability to acutely raise HDL-C can be assessed in cynomolgus monkeys. Animals are fed with standard primate maintenance diet. Compounds are formulated with appropriate vehicle and administered to animals by oral gavage. Blood is taken before and at several time-points after compound administration (usually 30 min, 1 h, 2 h, 4 h, 7 h and 24 h) . Plasma is separated from blood by low speed centrifugation and CETP activity and plasma lipids are quantified. Compound potency and efficacy can be assessed by measuring the HDL-C increase after this single-dose administration. In such pharmacodynamic model the extent together with the kinetics of the pharmacologic effect can be assessed.
- the compounds of formula I and their pharmaceutically acceptable salts and esters can be used as medicaments, e.g. in the form of pharmaceutical preparations for enteral, parente- ral or topical administration. They can be administered, e.g., perorally, e.g. in the form of tablets, coated tablets, dragees, hard and soft gelatine capsules, solutions, emulsions or suspensions, rectally, e.g. in the form of suppositories, parenterally, e.g. in the form of injection solutions or infusion solutions, or topically, e.g. in the form of ointments, creams or oils.
- the production of the pharmaceutical preparations can be effected in a manner which will be familiar to any person skilled in the art by bringing the described compounds of formula I and their pharmaceutically acceptable, into a galenical administration form to- gether with suitable, non-toxic, inert, therapeutically compatible solid or liquid carrier materials and, if desired, usual pharmaceutical adjuvants.
- Suitable carrier materials are not only inorganic carrier materials, but also organic carrier materials.
- lactose, corn starch or derivatives thereof, talc, stearic acid or its salts can be used as carrier materials for tablets, coated tablets, dragees and hard gelatine capsules.
- Suitable carrier materials for soft gelatine capsules are, e.g., vegetable oils, waxes, fats and semi- solid and liquid polyols (depending on the nature of the active ingredient no carriers are, however, required in the case of soft gelatine capsules).
- Suitable carrier materials for the production of solutions and syrups are, e.g., water, polyols, sucrose, invert sugar and the like.
- Suitable carrier materials for injection solutions are, e.g., water, alcohols, polyols, glycerol and vegetable oils.
- Suitable carrier materials for suppositories are, e.g., natural or hardened oils, waxes, fats and semi-liquid or liquid polyols.
- Suitable carrier materials for topical preparations are glycerides, semi-synthetic and synthetic glycerides, hydrogenated oils, liquid waxes, liquid paraffins, liquid fatty alcohols, sterols, polyethylene glycols and cellulose derivatives.
- Usual stabilizers preservatives, wetting and emulsifying agents, consistency- improving agents, flavour-improving agents, salts for varying the osmotic pressure, buffer substances, solubilizers, colorants and masking agents and antioxidants come into consideration as pharmaceutical adjuvants.
- the dosage of the compounds of formula I can vary within wide limits depending on the disease to be controlled, the age and the individual condition of the patient and the mode of administration, and will, of course, be fitted to the individual requirements in each particular case.
- a daily dosage of about 1 mg to about 1000 mg, especially about 1 mg to about 100 mg, comes into consideration.
- the pharmaceutical preparations conveniently contain about 0.1-500 mg, e.g., 0.5-100 mg, of a compound of formula I.
- Example A Film coated tablets
- the active ingredient is sieved and mixed with microcrystalline cellulose and the mixture is granulated with a solution of polyvinylpyrrolidon in water.
- the granulate is mixed with sodium starch glycolate and magesiumstearate and compressed to yield kernels of 120 or 350 mg respectively.
- the kernels are lacquered with an aqueous solution / suspension of the above mentioned film coat.
- the components are sieved and mixed and filled into capsules of size 2.
- the active ingredient is dissolved in a warm melting of the other ingredients and the mixture is filled into soft gelatin capsules of appropriate size.
- the filled soft gelatin capsules are treated according to the usual procedures.
Landscapes
- Chemical & Material Sciences (AREA)
- Organic Chemistry (AREA)
- Health & Medical Sciences (AREA)
- Veterinary Medicine (AREA)
- Public Health (AREA)
- Engineering & Computer Science (AREA)
- Medicinal Chemistry (AREA)
- Bioinformatics & Cheminformatics (AREA)
- Pharmacology & Pharmacy (AREA)
- Life Sciences & Earth Sciences (AREA)
- Animal Behavior & Ethology (AREA)
- General Health & Medical Sciences (AREA)
- Chemical Kinetics & Catalysis (AREA)
- General Chemical & Material Sciences (AREA)
- Nuclear Medicine, Radiotherapy & Molecular Imaging (AREA)
- Diabetes (AREA)
- Obesity (AREA)
- Cardiology (AREA)
- Hematology (AREA)
- Heart & Thoracic Surgery (AREA)
- Epidemiology (AREA)
- Emergency Medicine (AREA)
- Hospice & Palliative Care (AREA)
- Vascular Medicine (AREA)
- Endocrinology (AREA)
- Urology & Nephrology (AREA)
- Child & Adolescent Psychology (AREA)
- Pharmaceuticals Containing Other Organic And Inorganic Compounds (AREA)
- Organic Low-Molecular-Weight Compounds And Preparation Thereof (AREA)
- Pyridine Compounds (AREA)
- Acyclic And Carbocyclic Compounds In Medicinal Compositions (AREA)
- Plural Heterocyclic Compounds (AREA)
- Heterocyclic Carbon Compounds Containing A Hetero Ring Having Nitrogen And Oxygen As The Only Ring Hetero Atoms (AREA)
Abstract
Compounds of formula (I) wherein R1, R2, R4, R5, A, B, D and n are as defined, and pharmaceutically acceptable salts thereof, processes for their preparation, their use as pharmaceuticals and pharmaceutical compositions comprising them.
Description
BENZAMIDEAND HETEROARENE DERIVATIVES
The present invention relates to novel benzamide and heteroarene carboxamide derivatives, processes for their preparation, their use as pharmaceuticals and to pharmaceutical compositions comprising them.
More particularly, the present invention provides in a first aspect a compound of formula I
R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-Cόalkylsilyl; R2 is hydrogen or a group
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8- cycloalkyl, OH or halo-Ci-Cόalkoxy;
R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8. cycloalkyl, OH or halo-Ci-Cόalkoxy;
X is CR12 or N;
Y is CH or N; wherein X and Y are not N at the same time;
R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo- Ci-C6alkoxy;
Hei/ 14.12.06.
R5 is hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy; R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10 or N; B is CR11 or N; D is CR3 or N; wherein -B=A- and -A=D- are not -N=N-;
R3 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-Q-Ce. alkoxy;
R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen;
R » 11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
Examples of Ci-Cόalkyl include branched and straight-chain monovalent saturated aliphatic hydrocarbon radicals of one to six carbon atoms, e.g. methyl, ethyl, propyl, isopropyl, butyl, isobutyl, tert. -butyl, the isomeric pentyls and the isomeric hexyls.
Examples of halogen include fluorine, chlorine, bromine and iodine.
Examples of halo-Ci-Cόalkyl include Ci-Cόalkyl groups as defined above wherein at least one of the hydrogen atoms of the Ci-Cόalkyl group is replaced by a halogen atom, e.g. fluoro or chloro, e.g. trifluoromethyl, difluoromethyl, fluoromethyl, 1, 2,2,2- tetrafluoro-1- trifluoromethyl-ethyl, pentafluoroethyl and chlorodifluoromethyl.
Examples of halo-Ci-Cόalkoxy include alkoxy groups of formula O-Ci-Cόalkyl wherein at least one of the hydrogen atoms of the alkoxy group is replaced by a halogen atom, e.g. fluoro or chloro, e.g. trifluoromethoxy, difluoromethoxy, fluoromethoxy and chloro- difluoromethoxy.
Examples of Cs-Cscycloalkyl include saturated carbocyclic groups containing from 3 to 8 carbon atoms, such as cyclopropyl, cyclobutyl, cyclopentyl, cyclohexyl, cycloheptyl and cyclooctyl.
Examples of halo-Cs-Cscycloalkyl include 1-fluorocyclobutyl.
Examples of tri-Ci-Cόalkylsilyl include trimethylsilyl.
The term "pharmaceutically acceptable salts" refers to those salts which retain the biological effectiveness and properties of the free bases or free acids, which are not biologically or otherwise undesirable. The salts are formed with inorganic acids such as hydrochloric acid, hydrobromic acid, sulfuric acid, nitric acid, phosphoric acid and the like, preferably hydro- chloric acid, and organic acids such as acetic acid, propionic acid, glycolic acid, pyruvic acid, oxylic acid, maleic acid, malonic acid, salicylic acid, succinic acid, fumaric acid, tartaric acid, citric acid, benzoic acid, cinnamic acid, mandelic acid, methanesulfonic acid, ethanesulfonic acid, p-toluenesulfonic acid, salicylic acid, N-acetylcystein and the like. In addition these salts may be prepared from addition of an inorganic base or an organic base to the free acid. Salts derived from an inorganic base include, but are not limited to, the sodium, potassium, lithium, ammonium, calcium, magnesium salts and the like. Salts derived from organic bases include, but are not limited to salts of primary, secondary, and tertiary amines, substituted amines including naturally occurring substituted amines, cyclic amines and basic ion exchange resins, such as isopropylamine, trimethylamine, diethyl- amine, triethylamine, tripropylamine, ethanolamine, lysine, arginine, N-ethylpiperidine, piperidine, polymine resins and the like. The compound of formula I can also be present in the form of zwitterions. Particularly preferred pharmaceutically acceptable salts of compounds of formula I are the hydrochloride salts.
The compounds of formula I can also be solvated, e.g. hydrated. The solvation can be effected in the course of the manufacturing process or can take place e.g. as a consequence of hygroscopic properties of an initially anhydrous compound of formula I (hydration). The term pharmaceutically acceptable salts also includes physiologically acceptable solvates.
"Isomers" are compounds that have identical molecular formulae but that differ in the nature or the sequence of bonding of their atoms or in the arrangement of their atoms in space. Isomers that differ in the arrangement of their atoms in space are termed "stereoisomers". Stereoisomers that are not mirror images of one another are termed "diastereo-
isomers", and stereoisomers that are non-superimposable mirror images are termed "enan- tiomers", or sometimes optical isomers. A carbon atom bonded to four nonidentical sub- stituents is termed a "chiral center".
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, C3-C8cycloalkyl, halo-C3-C8cycloalkyl or tri-Ci-C6alkylsilyl. In another embodiment the present invention provides a compound of formula I wherein R1 is Ci-Cόalkyl. In still another embodiment the present invention provides a compound of formula I wherein R1 is butyl. In still another embodiment the present invention provides a compound of formula I wherein R1 is tert-butyl.
In one embodiment the present invention provides a compound of formula I wherein R2 is hydrogen.
In another embodiment the present invention provides a compound of formula I wherein R2 is a group (a). In another embodiment the present invention provides a compound of formula I wherein R2 is a group (a) wherein R6 and R7 are independently halo-Ci-Cόalkyl or halogen. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (a) wherein R6 halo-Ci-Cόalkyl and R7 is halogen. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (a) wherein R6 is CF3 and R7 is Cl.
In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b). In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R8 and R9 are independently hydrogen, halo- Ci-Cόalkyl, halogen, C3-C8cycloalkyl or halo-Ci-Cόalkoxy. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R8 and R9 are independently hydrogen, CF3, Cl, F, cyclopropyl or OCF3. In still another em- bodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R8 is hydrogen, CF3, Cl, F, cyclopropyl or OCF3. In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl or halo-Ci-Cόalkoxy. In still another embodiment the present invention provides a com- pound of formula I wherein R2 is a group (b) wherein R8 and R9 are independently hydrogen, CH2CH3, (CHi)2CH3, CH(CH3)2, CF3, Br, Cl, F, cyclopropyl or OCF3. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R8 is hydrogen, CH2CH3, (CH2)2CH3, CH(CH3)2, CF3, Br, Cl, F, cyclo-
propyl or OCF3. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R9 is hydrogen, Cl or F. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein R9 is hydrogen or F.
In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen or halo-Ci-Cόalkoxy. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl or halogen. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen or halogen. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, Cl or F. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl or halo-Ci-Cόalkoxy. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen or Cs-Cscycloalkyl. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, halogen or Cs-Cscycloalkyl. In still another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is CR12 wherein R12 is hydrogen, Cl, F or cyclopropyl.
In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein X is or N and Y is CH.
In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein Y is CH.
In another embodiment the present invention provides a compound of formula I wherein R2 is a group (b) wherein Y is N and X is CR12.
In another embodiment the present invention provides a compound of formula I wherein A is CR10. In still another embodiment the present invention provides a compound of formula I wherein A is CR10 wherein R10 is hydrogen, or is halo-Ci-Cόalkyl, halogen,
C3-C8cycloalkyl or OH, when at least one of R3, R4, R5 and R11 is not hydrogen. In still another embodiment the present invention provides a compound of formula I wherein A is CR10 wherein R10 is halo-Ci-C6alkyl or halogen, when at least one of R3, R4, R5 and R11 is not hydrogen. In still another embodiment the present invention provides a compound of formula I wherein A is CR10 wherein R10 is CF3 or Cl, when at least one of R3, R4, R5 and R11 is not hydrogen.
In another embodiment the present invention provides a compound of formula I wherein A is N and B and D are not N.
In another embodiment the present invention provides a compound of formula I wherein B is CR11. In another embodiment the present invention provides a compound of formula I wherein B is CR11 wherein R11 is hydrogen or is halogen, when at least two of R3, R4, R5 and R10 are not hydrogen. In another embodiment the present invention provides a compound of formula I wherein B is CR11 wherein R11 is hydrogen or is F or Cl, when at least two of R3, R4, R5 and R10 are not hydrogen. In still another embodiment the present inven- tion provides a compound of formula I wherein B is CR11 wherein R11 is hydrogen.
In another embodiment the present invention provides a compound of formula I wherein B is N and A is not N.
In another embodiment the present invention provides a compound of formula I wherein D is CR3. In still another embodiment the present invention provides a compound of formula I wherein D is CR3 wherein R3 is hydrogen.
In another embodiment the present invention provides a compound of formula I wherein D is N.
In another embodiment the present invention provides a compound of formula I wherein R5 is hydrogen, halo-Ci-Cόalkyl, halogen or OH. In still another embodiment the present invention provides a compound of formula I wherein R5 is hydrogen, halo-Ci-Cόalkyl or halogen. In still another embodiment the present invention provides a compound of formula I wherein R5 is hydrogen or halogen. In still another embodiment the present invention provides a compound of formula I wherein R5 is hydrogen or F.
In another embodiment the present invention provides a compound of formula I wherein R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl or halogen when at least one of R3, R5, R10 and R11 is not hydrogen. In still another embodiment the present invention provides a
compound of formula I wherein R4 is halo-Ci-Cόalkyl or halogen and at least one of R3, R5, R10 and R11 is not hydrogen. In still another embodiment the present invention provides a compound of formula I wherein R4 is CF3 or Cl and at least one of R3, R5, R10 and R11 is not hydrogen. In still another embodiment the present invention provides a compound of formula I wherein R4 is Ci-Cόalkyl, halo-Ci-Cόalkyl or halogen and at least one of R3, R5, R10 and R11 is not hydrogen. In still another embodiment the present invention provides a compound of formula I wherein R4 is CH2CH3, CF3 or Cl and at least one of R3, R5, R10 and R11 is not hydrogen.
The present invention provides compounds of formula I wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen.
In another embodiment the present invention provides a compound of formula I wherein n is 1.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl;
R2 is hydrogen; R5 is hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy;
R -.4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen;
A is CR10 or N;
B is CR11 or N;
D is CR3 or N; wherein -B=A- and -A=D- are not -N=N-; R3 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo- Ci-Cόalkoxy;
R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen;
R » 11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C6alkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-Cόalkylsilyl; R2 is a group
R6 —N \ (a)
wherein R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-Ci-Cόalkoxy; R5 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy; R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10 or N; B is CR11 or N; D is CR3 or N; wherein -B=A- and -A=D- are not -N=N-;
R3 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy; R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen; R ) 11 is hydrogen or is Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo- Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl; R2 is a group
wherein
R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8- cycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N;
Y is CH or N; wherein X and Y are not N at the same time; R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R5 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10 or N; B is CR11 or N; D is CR3 or N; wherein -B=A- and -A=D- are not -N=N-; R3 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen;
R ) 11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl;
R2 is hydrogen or a group
wherein
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-Cs- cycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-Cs- cycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N; Y is CH or N; wherein X and Y are not N at the same time; R12 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R5 is hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy;
R -.4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo- Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen;
A is CR10;
B is CR11 or N;
D is CR3 or N;
R3 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-C6alkoxy;
R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen;
R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-Cόalkylsilyl;
R2 is hydrogen or a group
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8- cycloalkyl, OH or halo-Ci-Cόalkoxy;
R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8- cycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N; Y is CH or N; wherein X and Y are not N at the same time;
R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R5 is hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5 and R11 is not hydrogen; A is N; B is CR11; D is CR3; R3 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl;
R2 is hydrogen or a group
wherein
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8- cycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-C8- cycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N; Y is CH or N; wherein X and Y are not N at the same time; R12 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-
Ci-Cόalkoxy; R5 is hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy;
R -.4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen;
A is CR10;
B is CR11 or N;
D is CR3;
R3 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-Ci- C6alkoxy;
R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen;
R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl; R2 is a group
wherein
R8 and R9 are independently hydrogen, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl or halo-Ci-Cόalkoxy; X is CR12;
Y is CH;
R12 is hydrogen or halogen; R5 is hydrogen or halogen; R4 is h alo - C i - Cόalkyl or h alo gen ; A is CR10;
B is CR11 or N; D is CR3; R3 is hydrogen;
R10 is halo-Ci-C6alkyl or halogen; R11 is hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In one embodiment the present invention provides a compound of formula I wherein R1 is Ci-C6alkyl; R2 is a group
R8 and R9 are independently hydrogen, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl or halo-Ci-Cόalkoxy;
X is CR12; Y is CH;
R12 is hydrogen, halogen or Cs-Cscycloalkyl; R5 is hydrogen or halogen;
R4 is Ci-C6alkyl, halo-Ci-C6alkyl or halogen; A is CR10; B is CR11 or N; D is CR3; R3 is hydrogen;
R10 is halo-Ci-C6alkyl or halogen; R11 is hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
In addition to the foregoing the present invention also provides a process for the production of a compound of formula I
R2 is hydrogen or a group
Cscycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cscycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N; Y is CH or N;
wherein X and Y are not N at the same time;
R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy;
R3 and R5 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3- Cecycloalkyl, OH or halo-Ci-Cόalkoxy;
R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10 or N; B is CR11 or N; D is CR3 or N; wherein -B=A- and -A=D- are not -N=N-;
R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen; R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; which process comprises reacting an acid derivative, a compound of formula II
If carboxylic acids (W=OH) or carboxylate salts (W=OIi, ONa, OK) of formula II are used in this process, standard peptide coupling reagents can be applied to activate the acid prior to the coupling reaction. Typically, the acid derivative II (R=OH, 0Ii, ONa, OK) is mixed
with a coupling reagent such as EDC or EDC HCl, DCC, HBTU or TBTU in an inert solvent such as N,N-dimethylformamide, dimethylacetamide (DMA) or dichloromethane (DCM) together with the appropriate secondary amine derivative III. Optionally a base (e.g. iV,iV-diisopropylethyl amine, triethylamine, iV-methyl morpholine) and/or 1- hydroxybenzotriazole (HOBT) can be added. The reaction mixture is stirred for 1 to 24 h at a temperature of about -3O0C to about 7O0C (e.g. ambient temperature).
Alternatively, acid chlorides (W=Cl) can be reacted with secondary amine derivatives III to obtain formula (I) compounds, using standard protocols.
Acid derivatives of formula II are commercially available or can be prepared as described in the example section.
Secondary amines of the general formula III can be synthesized by standard methods. They may be synthesized as outlined below.
Compounds of formula III
wherein
R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-
Cecycloalkyl or tri-Ci-Cόalkylsilyl; R2 is hydrogen or a group
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cscycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cecycloalkyl, OH or halo-Ci-Cόalkoxy; X iiss CCRR1122 oorr NN; Y is CH or N;
wherein X and Y are not N at the same time;
R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy; and n is 1, 2 or 3; may be prepared by reductive amination of a benzaldehyde derivative, a compound of formula IV
wherein R1 is as defined above, with an amine, a compound of formula V
wherein R and n are as defined above.
The necessary starting amines and aldehydes are commercially available or are synthesized using standard methods as e.g. described in the example section.
Secondary amines III may alternatively be synthesized from amide derivatives, compounds of formula VII
wherein R1, R2 and n are as defined above.
Amide derivatives, compounds of formula VII are available by the coupling of benzoic acid derivatives, compounds of formula VI
(VI)
wherein R1 is as defined above, with a compound of formula V.
The necessary starting benzoic acids are commercially available or may be synthesized using standard methods as e.g. described in the example section.
The following abbreviations are used: RT: room temperature; THF: tetrahydrofuran; DMF: N,N-dimethylformamide; DCM: dichloromethane
In general, the nomenclature used in this Application is based on AUTONOM™ v.4.0, a Beilstein Institute computerized system for the generation of IUPAC systematic nomenclature.
Aldehydes (Acids) (Compounds of formula IV and VI):
Example Sl-A: Preparation of 4-cyclopropyl benzaldehyde:
To a solution of l-bromo-4-cyclopropylbenzene [synthesized in analogy to a procedure described in J.Org.Chem. 1976, 41, 2262-2266] (1.58 g, 8.04 mmol) in THF at -780C was added n-BuIi (5.08 ml, 1.6M solution in hexane, 8.11 mmol) and the reaction mixture was stirred at -780C for 10 min. DMF (1.25 ml, 16.08 mmol) was then added and the reaction mixture was stirred at -780C for 15 min. The reaction mixture was then warmed to O0C slowly (over 2h) and stirred at O0C for Ih. The reaction was quenched with sat. NH4Cl (aq) solution and the aqueous phase was extracted with ether. The organic layer was washed with brine, dried (MgSO4), filtered and concentrated in vacuo to give a residue which was purified by flash column chromatography (1:9 diethyl ether/pentane) to give 4-cyclopropyl benzaldehyde (1.10 g, 94%) as a colourless oil. m NMR (CDCl3, 300 MHz): δ 9.94 (s, IH), 7.76 (d, J=8.5 Hz, 2H), 7.19 (d, J=8.5 Hz, 2H), 1.97 (m, IH), 1.13-1.06 (m, 2H), 0.84-0.78 (m, 2H).
Example S2-A: Preparation of 4-cyclobutyl benzaldehyde:
a) Preparation of l-(4-bromophenyl)-cyclobutanol:
To a solution of 1, 4-dibromobenzene (1.00 g, 4.24 mmol) at -780C in ether (20 ml) was added π-BuIi (2.65 ml, 1.6 M solution in hexane, 4.24 mmol) and the reaction mixture was stirred at -780C for 30 min. Cyclobutanone (348 μl, 4.66 mmol) was then added and the reaction mixture was stirred at -780C for 15 min. The reaction mixture was then slowly (over 2h) warmed to O0C. and stirred for a further Ih. Water was added followed by sat.
NH4Cl and the reaction mixture was extracted with ether. The organic layer was washed with brine, dried (MgSO4), filtered and concentrated in vacuo to give a residue which was purified by flash column chromatography (1:4 ether/pentane) to give l-(4-bromophenyl)- cyclobutanol (330 mg, 34%) as a colourless oil. m NMR (CDCl3, 300 MHz): δ 7.50 (d, J=8.5 Hz, 2H), 7.38 (d, J=8.5 Hz, 2H), 2.57-2.48 (m, 2H), 2.41-2.31 (m, 2H), 2.02 (m, IH), 1.69 (m, IH).
b) Preparation of l-bromo-4-cyclobutyl-benzene:
To a solution of 1.37 g of l-(4-bromophenyl)-cyclobutanol (6 mmol) in 15 ml DCM were added 1.15 ml of triethylsilane (7.2 mmol) and the mixture was cooled to -780C. Then 1.15 ml of boron trifluoride diethyl etherate complex were added and the reaction mixture was warmed to -4O0C and stirred for 8 h. The reaction was then quenched by addition of 10% aqueous KHCO3 and the mixture was extracted three times with DCM. The combined extracts were washed with brine, dried with magnesium sulfate and concentrated. The remaining residue was purified by column chromatography (silica gel; cyclohexane) to give 0.84 g (66%) of l-bromo-4-cyclobutyl-benzene as a colorless liquid. m NMR (CDCl3, 300
MHz): δ 1.85 (m, IH), 1.92-2.18 (m, 3H), 2.33 (m, 2H), 3.49 (quint, J=8.5 Hz, IH), 7.08 (d, J=8.5 Hz, 2H), 7.40 (d, J=8.5 Hz, 2H).
c) Preparation of 4-cyclobutyl-benzaldehyde:
The title compound was synthesized in analogy to 4-cyclopropyl benzaldehyde (described in example Sl-A) using 830 mg of l-bromo-4-cyclobutyl-benzene (3.93 mmol), 2.7 ml of a 1.6 molar solution of n-BuIi in hexane (4.32 mmol) and 605 μl of DMF (7.86 mmol). The isolated residue was purified by flash column chromatography (5:95 EtOAc/cyclohexane) to give 422 mg of 4-cyclobutyl-benzaldehyde (67%) as a colourless liquid. m NMR (CDCl3,
300 MHz): δ 1.89 (m, IH), 1.97-2.26 (m, 3H), 2.40 (m, 2H), 3.63 (quint, J=8.5 Hz, IH), 7.36 (d, J=8.0 Hz, 2H), 7.81 (d, J=8.0 Hz, 2H), 9.97 (s, IH).
Example S3-A: Preparation of 4-(l-fluoro-cyclobutyl)-benzaldehyde:
a) Preparation of l-bromo-4-(l-fluoro-cyclobutyl)-benzene:
To a solution of 5.66 g of l-(4-bromophenyl)-cyclobutanol (24.92 mmol, described in example S2-A) in 70 ml DCM were added 4.23 g of (diethylamino)sulfur trifluoride (95%, 24.92 mmol) at O0C. The reaction mixture was stirred at O0C for 35 min, then sat.
NaHCO3- solution was added and the resulting mixture was extracted with DCM. The combined organic extracts were washed with brine, dried (MgSO4), filtered, and con-
centrated in vacuo to give a residue which was purified by flash column chromatography (100% pentane) to give l-bromo-4-(l-fluoro-cyclobutyl)-benzene (3.66 g, 64%) as a colourless liquid.
b) Preparation of 4-(l-fluoro-cyclobutyl)-benzaldehyde: The title compound was synthesized in analogy to 4-cyclopropyl benzaldehyde (described in example Sl-A) using 1.64 g of l-bromo-4-(l-fluoro-cyclobutyl)-benzene (7.16 mmol), 4.92 ml of a 1.6 molar solution of n-BuIi in hexane (7.87 mmol) and 1.1 ml of DMF (14.32 mmol). 4-(l-Fluoro-cyclobutyl)-benzaldehyde was isolated as crude product as a light yellow liquid (1.23 g, 96%). 1H NMR (CDCl3, 300 MHz): δ 1.84 (m, IH), 2.15 (m, IH), 2.49-2.81 (m, 5H), 7.63 (d, J=8 Hz, 2H), 7.92 (d, J=8 Hz, 2H), 10.03 (s, IH).
Example S4-A: Preparation of 4-(l,2,2,2-tetrafluoro-l-trifluoromethyl-ethyl)- benzaldehyde
A solution of 3.5 g of 4- (heptafluoroisopropyl) -toluene (13.4 mmol) in lOO ml tetra- chloromethane was heated to reflux. Then 2.63 g of N-bromosuccinimide (14.8 mmol) and 326 mg of dibenzoyl peroxide ( 1.34 mmol) were added in small portions. After 5 h the mixture was cooled to O0C, filtered and the solvent was evaporated. The remaining residue was dissolved in 15 ml ethanol and was added to a suspension that had been prepared by addition of 2-nitropropane (1.4 ml, 15.5 mmol) to a solution of 340 mg sodium (14.8 mmol) in ethanol. This mixture was stirred for 3 days. Then it was filtered, the solvent was removed and the remaining residue was dissolved in EtOAc and washed with 1 N sodium hydroxide solution, 1 N HCl solution, saturated NaHCO3 solution and with brine. The EtOAc layer was then dried with magnesium sulfate, filtered and concentrated. Purification of the residue (silica gel; c-hexane/EtO Ac 10:1) gave 1.1 g (30%) of 4- (1,2,2,2- tetrafluoro- l-trifluoromethyl-ethyl)-benzaldehyde as a light yellow oil. 1H-NMR (CDCl3, 300 MHz: δ 7.82 (d, J=8 Hz, 2H), 8.03 (d, J=8 Hz, 2H), 10.11 (s, IH).
Example S5-A: Preparation of 4-pentafluoroethyl-benzoic acid
a) Preparation of 4-pentafluoroethyl-benzonitrile:
A mixture of 4-iodobenzonitrile (10.0 g, 43.7 mmol), sodium pentafluoroproprionate (15.4 g, 82.9 mmol), and copper(I) iodide (16.6 g, 87.3 mmol), DMF (160 mL), and toluene (60 mL) was heated at 16O0C for 16 h, allowing most of the toluene to distil off. After cooling, ethyl acetate (200 mL) was added, and the mixture was filtered through diatomaceous earth, and the filtrate was partitioned between ethyl acetate/heptane and
water. The organic layer was washed with brine, dried (MgSO4), and evaporated. Chromatography (SiO2, heptane-ethyl acetate gradient) afforded the title compound (5.05 g 52%). Yellow oil, MS (EI) 221.1 (M+).
b) Preparation of 4-pentafluoroethyl-benzoic acid A mixture of 4-pentafluoroethyl-benzonitrile (2.98 g, 13.5 mmol) and potassium hydroxide (3.03 g, 54.0 mmol) in water (40 mL) and ethanol (20 mL) was heated at reflux for 16 h. After cooling, the solution was partitioned between 1 M aq. hydrochloric acid solution and ethyl acetate. The organic layer was washed with brine, dried (MgSO4), and evaporated. Chromatography (SiO2, heptane-ethyl acetate gradient) produced the title compound (2.76 g, 85%) . White solid, MS (ISP) 238.9 (M-H)".
Example S6- A: Preparation of 4-trimethylsilanyl-benzaldehyde
l-Bromo-4-(trimethylsilyl)benzene (1.15 g, 5 mmol) was dissolved in THF (30 ml) and cooled to -780C. Under argon a 1.6 M solution of n-butyl lithium in hexane (3.13 ml, 5 mmol) was added dropwise keeping the temperature below -7O0C. The clear colorless solution was stirred at -780C for 15 min and DMF (1.156 ml, 15 mmol) was added quickly. The reaction temperature increased to -680C. The reaction was stirred for additional 15 min at -780C, quenched with IN aqueous hydrogen chloride solution and extracted twice with diethyl ether. The combined organic layers were washed twice with water and once with saturated aqueous sodium chloride solution, dried over sodium sulfate, filtered and the solvent was evaporated to leave the product as a colorless oil (920 mg, 100 %). The product was pure enough to be used directly in the next step. MS (ISP) 179.2 (M+H+). m NMR (CDCl3, 300MHz): δ 10.02 (s, IH) 7.84 (d, 2H), 7.69 (d, 2H), 0.31 (s, 9H).
Example S7-A: Preparation of 4-(l,l-dimethylpropyl)-benzaldehyde
The title compound was synthesized in analogy to example Sl-Ausing l-bromo-4-(l,l- dimethylpropyl) -benzene (synthesized in analogy to a procedure described in J.Chem. Res. Miniprint., 1997, 12, 2701-2733) (250mg, l.lOmmol), nBυlA (825μl, 1.6M solution in hexane, 1.32mmol) and DMF (427 μl, 5.50mmol). The isolated residue was purified by flash column chromatography (1:9 etheπpentane) to give 4-(l,l-dimethylpropyl)-benz- aldehyde (175mg, 90%) as a colourless oil. 1U NMR (CDCl3, 300MHz): 9.99 (s, IH), 7.82 (d, J=8.5Hz, 2H), 7.50 (d, J=8.5Hz, 2H), 1.69 (q, J=7.5Hz, 2H), 1.32 (s, 6H), 0.68 (t, J=7.5Hz, 3H).
Primary amines (Compounds of formula V):
Example Sl-B: Preparation of 2-(3-fluoro-5-trifluoromethyl-phenyl)-ethylamine hydrochloride
5.45 g of (3-fluoro-5-trifluoromethyl-phenyl)-acetonitrile (26.3 mmol) were dissolved in 45 ml THF and cooled down to O0C under nitrogen. 138 ml borane-tetrahydrofuran com- plex IM ( 138 mmol) were then added dropwise over 20 min by keeping the temperature between 0-20C. After addition the reaction mixture was stirred at RT for additional 45 min, and refluxed for 17 h. The reaction mixture is then cooled down to O0C and treated between 2 and 50C with 33 ml methanol over a period of 45 min. After 1 hour refluxing the reaction mixture is concentrated, the residue dissolved in DCM and the amine extrated twice with IN aqueous HCl. The combined aqueous phases are then treated with concentrated NaOH to adjust the pH to 12, and then extrated twice with DCM. The combined organic phases were then washed with water, dried over magnesium sulfate, filtered and concentrated in vacuo leading to 4.44 g colorless oil. This was dissolved in 100 ml diethyl- ether, treated with 9 ml 2.6N HCl in diethylether, stirred at RT for additional 30 min, filtered and dried under high vacuo, leading to 4.6 g white solid (72 %) . MS (ISP) 207.1 (M+H)+.
Example S2-B: Preparation of 2-(4-chloro-3-trifluoromethyl-phenyl)-ethylamine hydrochloride
a) Preparation of (4-chloro-3-trifluoromethyl-phenyl)-acetonitrile: 3.94 g of 4-bromomethyl-l-chloro-2-trifluoromethyl-benzene (14.4 mmol) and 1.06 g sodium cyanide (21.6 mmol) were suspended in 12 ml DMSO under argon and stirring
and heated to 5O0C for 1 h. The reaction mixture was then poured on water/ice and extracted four times with DCM. The combined organic phases were washed with water, dried with magnesium sulfate, filtered and concentrated in vacuo, leading to 3.188 g of (4- chloro-3-trifluoromethyl-phenyl)-acetonitrile as a dark red oil, which was directly used in the next step.
b) Preparation of 2-(4-chloro-3-trifluoromethyl-phenyl)-ethylamine hydrochloride: The title compound was synthesized in analogy to 2-(3-fluoro-5-trifluoromethyl-phenyl)- ethylamine hydrochloride (described in example Sl-B) from 3.188 g of crude (4-chloro-3- trifluoromethyl-phenyl)-acetonitrile (14.5 mmol) and 76 ml of a IM borane-THF complex solution in THF (76 mmol). The product was obtained as a white solid (1.52 g, 40%). MS (ISP) 224.1 (M+H)+.
Example S3-B: Preparation of 2-(4-chloro-3-fluoro-phenyl)-ethylamine (S3-B1)
a) Preparation of l-chloro-2-fluoro-4-(2-nitro-vinyl)-benzene: 4-Chloro-3-fluorobenzaldehyde (13g, 82mmol) and ammonium acetate (14.6g, 189mmol) were dissolved in acetic acid (150ml) and nitromethane (12.6ml, 234mmol) was added. The solution was heated to reflux for 1.5h. After cooling to RT water (120ml) was added. A solid precipitated. The reaction was extracted three times with methylene chloride. The combined organic layers were washed with water and sat. aq. NaCl solution, dried over magnesium sulfate, filtered and the solvent was removed in vacuo. The residue was puri- fied by flash column chromatography (Ethyl acetate/cyclohexane: 1/4) . The crude product was suspended in heptane, filtered and dried to yield l-chloro-2-fluoro-4-(2-nitro-vinyl)- benzene (10.9g, 66%) as a light yellow solid. m NMR (CDCl3, 300MHz): δ 7.29 (d, J=7.8 Hz, IH), 7.33 (d, J=9.3 Hz, IH), 7.50 (t, J=7.5 H7, IH), 7.54 (d, J= 13.6Hz, IH), 7.92 (d, J= 13.6 Hz, IH).
b) Preparation of 2-(4-chloro-3-fluoro-phenyl)-ethylamine:
Lithium borohydride (2.16g, 99 mmol) was suspended in THF (50ml). Trimethylchloro- silane (21.6g, 198mmol) was added dropwise. A solution of l-chloro-2-fluoro-4-(2-nitro- vinyl) -benzene (5.Og, 24.8mmol) in THF (20ml) was added dropwise. Strong gas evolution and foam formation was observed. The white suspension was stirred at RT for 3 days. Carefully MeOH (80ml) was added. The solvents were removed in vacuo and the residue was purified by flash column chromatography (CH2Cl2 / MeOH+5%aq. NH4OH 4:1) to yield 2-(4-chloro-3-fluoro-phenyl)-ethylamine (3.1g, 73%) as a white solid. MS (ISP)
174.1 (M+H)+. mNMR (DMSO-d6, 300 MHz): δ 2.92 (t, J=4.8 Hz, 2H), 3.02 (t, J=6.3Hz, 2H), 7.15 (dd, J=6.0 and 1.2 Hz, IH), 7.38 (dd, J= 1.2 and 7.8Hz), 7.53 (t, J=6.3 Hz, IH), 7.93 (br, 2H).
*: Prepared in analogy to example
Example S4-B: Preparation of 2-(3-bromo-4-chlorophenyl)-ethylamine: a) Preparation of (3-bromo-4-chlorophenyl)-acetonitrile:
The title compound was synthesized in analogy to example S2-B using 2-bromo-4-bromo- methyl-1-chlorobenzene (prepared in analogy to a procedure described in J.Med.Chem.; 2003; 46(20), 4232 - 4235) (570 mg, 2.00 mmol) and sodium cyanide (147 mg, 3.00 mmol) to give the desired product as a dark red oil which was reacted on without further purification. b) Preparation of 2-(3-bromo-4-chlorophenyl)-ethylamine:
The title compound was synthesized in analogy to example Sl-B using crude (3-bromo-4- chlorophenyl)-acetonitrile (475 mg, 2.06 mmol) and IM borane-THFcomplex (4.12 ml,
4.12mmol). The product was obtained as a colorless oil (300 mg, 62%). MS (ISP) 236.0
(M+H)+.
Example S5-B: Preparation of 2-(4-chloro-3-ethyl-phenyl)-ethylamine hydrochloride
a) Preparation of 4-chloro-3-ethyl-benzaldehyde:
To a solution of 4.319 g of 4-bromo-l-chloro-2-ethyl-benzene (20 mmol) in 50 ml diethyl- ether, cooled to O0C, were added drop wise 12.3 ml of 1.6M n-BuIi in hexane. After 30 min. stirring at O0C and 2 h at RT, a solution of 2.43 ml DMF (31 mmol) in 10 ml diethylether was added dropwise (temperature raised from 20 to 280C). After 1 h additional stirring at RT, the reaction mixture was acidified with 2N HCl, diluted with 150 ml water and extracted with diethylether. The combined organic layers were washed with brine, dried over magnesium sulfate, filtered off and concentrated in vacuo. The residue was purified by flash column chromatography (heptane / AcOEt: 95/5) to yield 2.1 g of a colorless oil. MS (ISP) 168.1 (M+H)+. b) Preparation of 2-(4-chloro-3-ethyl-phenyl)-ethylamine hydrochloride:
The title compound was prepared from 4-chloro-3-ethyl-benzaldehyde in analogy to example S3-B1 steps a) and b). MS (ISP) 184.1 (M+H)+.
Example S6-B: Preparation of 2-(4-benzyloxy-3-tert-butyl-phenyl)-ethylamine hydrochloride
a) 1-Benzyloxy- 2- tert-butyl-4- methyl-benzene:
8 g of 2-tert-Butyl-4-methyl-phenol (49 mmol) and 16.36 g of potassium carbonate (58 mmol) were stirred in 120 ml DMF until a suspension was formed. 6.74 ml of benzyl- chloride were then added dropwise and the reaction mixture was stirred for 24 h at RT.
After two hours heating at 6O0C, the reaction mixture was cooled to RT, filtered off, diluted with ethyl acetate, and washed with water followed by brine. The organic phase was dried over magnesium sulphate, filtered off and concentrated under vacuo. The residue was purified by flash column chromatography (heptane/ AcOEt 98/2) to give 8.647 g of a colourless liquid. MS (ISP) 255.3 (M+H)+. b) Preparation of 4-benzyloxy-3-tert-butyl-benzaldehyde:
A solution of 6.985 g l-benzyloxy-2-tert-butyl-4-methyl-benzene (27 mmol) and 115 g ammoniumcer(IV) -nitrate in 1000 ml acetic acid (50%v/v) was stirred at 9O0C for one hour. After cooling down to RT, the reaction mixture was extracted with AcOEt/heptane 1:9, dried over magnesium sulfate, filtered off and concentrated under vacuo. The residue was purified by flash column chromatography (heptane/ AcOEt 95/5 to 90/10) to give 3.48 g of an orange solid. MS (ISP) 269.3 (M+H)+. c) Preparation of 2-(4-benzyloxy-3-tert-butyl-phenyl)-ethylamine hydrochloride:
The title compound was prepared from 4-benzyloxy-3-tert-butyl-benzaldehyde in analogy to example S3-B1 steps a) and b). MS (ISP) 284.2 (M+H)+.
Secondary amines (Compounds of formula III):
Example Sl-C: Preparation of (4-?e/t-butyl-benzyl)-[2-(3,4-dichloro-phenyl)-ethyi]- amine
0.38 ml of 4-tøt-butylbenzaldehyde (2.25 mmol) and 0.227 ml 2-(3,4-dichloro-phenyl)- ethylamine (1.5 mmol) were dissolved in 4.5 ml methanol at RT, and after stirring for 30 min at RT, were refluxed for 2 h. After cooling down to RT, 85 mg (2.25 mmol) sodium borohydride were added and after stirring for 5 min at RT, the reaction mixture was then refluxed for 2 h. After cooling down to RT, the reaction mixture was treated with 4 drops 1 N HCl and concentrated in vacuo. The residue was diluted with water/ EtOAc. After separation of the organic phase, the aqueous phase was extracted with EtOAc and the combined organic phases were washed with brine, dried with magnesium sulfate, filtered off and concentrated in vacuo. The residue was purified by column chromatography (40 g silica gel; EtOAc /heptane 1:2) to give 515 mg colorless viscous oil (97 %). MS (ISP) 336.2 (M+H)+.
Example S2-C: Preparation of (4-?e/t-butyl-benzyl)-[2-(4-fluoro-3-trifluoromethyl- phenyl)-ethyl] -amine
0.62 ml of 4-tøt-butylbenzaldehyde (3.69 mmol), 600 mg of 2-(4-fluoro-3-trifluoro-meth- yl-phenyl)-ethylamine hydrochloride (2.46 mmol) and 340 mg of potassium carbonate (2.46 mmol) were suspended in 7 ml methanol at RT, and after stirring for 30 min at RT, were refluxed for 2 h. After cooling down to RT, 140 mg (3.69 mmol) of sodium borohydride were added and after stirring for 5 min at RT, the reaction mixture was then refluxed for 3 h. After cooling down to RT, the reaction mixture was treated with 0.5 ml 1 N HCl and concentrated in vacuo. The residue was diluted with water/ EtOAc. After separation of the organic phase, the aqueous phase was extracted with EtOAc and the combined organic phases were washed with brine, dried with magnesium sulfate, filtered off and concentrated in vacuo. The residue was purified by column chromatography (40 g silica gel; EtOAc /heptane 1:4 then 1:2) to give 784 mg light yellow oil (90 %). MS (ISP) 354.3 (M+H)+.
Example S3-C: Preparation of (4-cyclopropylbenzyl)-[2-(3,4-dichlorophenyl)-ethyl]- amine
Amixture of 4-cyclopropyl benzaldehyde (219mg, 1.50 mmol), 2-(3,4-dichlorophenyl)- ethylamine (284mg, 1.50 mmol) and molecular sieves (500 mg, 4A) in diethyl ether (5ml) was stirred at RT overnight. The mixture was filtered through celite®and concentrated in vacuo to give the corresponding imine which was dissolved in methanol. Sodium boro- hydride (85 mg, 2.25 mmol) was added and the reaction mixture was stirred at RT for 4h. The reaction mixture was then quenched with 0.1N NaOH (aq) and the mixture was diluted with EtOAc and washed with brine. The organic phase was dried (MgSO4), filtered and concentrated in vacuo to give the desired (4-cyclopropylbenzyl)-[2-(3,4-dichlorophenyl)- ethyl] -amine (317mg, 75%) without further purification as a colourless oil. MS (ISP) 320.2 (M+H)+.
Example S4-C: Preparation of (4-tert-butyl-benzyl)-[2-(2-chloro-pyridin-4-yl)-ethyl]- amine
a) Preparation of 2-chloro-4-trimethylsilanylethynyl-pyridine:
Amixture of 2.5 g of 4-bromo-2-chloropyridine (12.6 mmol), 2.2 ml of (trimethylsilyl)- acetylene (15.1 mmol), 153 mg of copper(I)iodide (0.79 mmol) and 287 mg of bis(tri- phenylphosphine)palladium(II)chloride (0.41 mmol) in triethylamine (15 ml) was stirred at RT for I h. The triethylamine was then removed in vacuo, water was added and the mix- ture was extracted with diethylether. The combined organic extracts were then washed with water and brine, dried (Na2SO4), filtered and concentrated in vacuo to give a residue which was purified by column chromatography (heptane/EtOAc 100:0 to 98:2) to give 2-chloro- 4-trimethylsilanylethynyl-pyridine (2.394 g, 91%) as a light yellow liquid. MS (ISP) 210.1 (M+H)+.
b) Preparation of 2-chloro-4-ethynyl-pyridine:
To a solution of 2.389 g of 2-chloro-4-trimethylsilanylethynyl-pyridine (11.39 mmol) in THF (90 ml) were added 11.39 ml of a IM TBAF solution in THF at -780C and the reaction mixture was stirred for 45 min at O0C. Then saturated NH4Cl solution was added and the THF was removed under reduced pressure. The aqueous mixture was extracted with di- ethylether and the combined organic extracts were washed with water and brine, dried (Na2SO4), filtered and concentrated in vacuo. The remaining residue was purified by column chromatography (pentane/ diethylether 100:0 to 4:1) to give 2-chloro-4-ethynyl-
pyridine (1.427 g, 91%) as an off-white solid. m-NMR (CDCl3, 300 MHz: δ 3.36 (s, IH), 7.27 (dd, J=5 and 1 Hz, 2H), 7.40 (br s, IH), 8.37 (d, J=8 Hz, 2H).
c) Preparation of (4-tert-butyl-benzyl)-[2-(2-chloro-pyridin-4-yl)-ethyl] -amine: A mixture of 1.386 g of 2-chloro-4-ethynyl-pyridine (10.07 mmol), 2.65 ml of 4-tert-butyl- benzylamine (15.11 mmol), 0.58 ml of acetic acid (10.07 mmol) and 666 mg of sodium cyanoborohydride (95% purity, 10.07 mmol) in ethanol (12 ml) were heated to 1050C in a sealed tube for 2 d. The reaction mixture was allowed to cool to RT, diluted with 3N NaOH solution and extracted with DCM. The combined organic extracts were washed with saturated NaHCO3 solution and brine, dried (Na2SO4), filtered and concentrated in vacuo. After column chromatography (heptane/EtOAc 100:0 to 0:100) 1.688 g (55%) of the title compound were isolated as a brown liquid. MS (ISP) 303.2 (M+H)+.
Example S5-C: Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-trifluoromethylpyr- azol-1-yl) -ethyl] -amine and (4-?e/t-butylbenzyl)-[2-(4-chloro-5-tri- fluoromethylpyrazol-l-yl)-ethyl]-amine
a) Preparation of 4-chloro-3-trifluoromethyl-lH-pyrazole:
To a solution of 3-trifluoromethyl- lH-pyrazole (500 mg, 3.67 mmol) in glacial acetic acid (5 ml) was added a 10% solution of sodium hypochlorite in water (2188 μl, 3.67 mmol). The reaction mixture was stirred at RT overnight and then neutralized with sat. sodium carbonate, and extracted with DCM. The organic layers were combined washed with brine, dried (MgSO4), filtered and concentrated in vacuo to give the desired product (480 mg, 77%) as a white solid which did not require further purification. MS (ISP) 169.0 (M-H)".
b) Preparation of 2-(4-tøf-butylbenzylamino)-ethanol:
The title compound was synthesized in analogy to example S3-C using 4-tøt-butylbenz- aldehyde (1000 mg, 6.17 mmol), ethanolamine (371 μl, 6.17 mmol) and sodium boro- hydride (350 mg, 9.25 mmol) . The desired product ( 1190 mg, 93%) was isolated without further purification as a colourless oil. MS (ISP) 208.3 (M+H)+.
c) Preparation of 3-(4-tert-butylbenzyl)-[l,2,3]oxathiazolidine 2,2-dioxide:
To a solution of 2-(4-tøt-butylbenzylamino)-ethanol (1190 mg, 5.74 mmol) and triethyl- amine (3200 μl, 22.96 mmol) in DCM (15 ml) at -150C was added a solution of thionyl- chloride (544 μl, 7.46 mmol) in DCM (4 ml) over 10 min. The reaction mixture was stirred at - 1O0C for 30min, filtered and the filtrate was concentrated in vacuo. The residue was purified by flash column chromatography to give the desired compound (790 mg, 54%) as
a white solid. To a mixture of 3-(4-tøt-butylbenzyl)-[l,2,3]oxathiazolidine 2-oxide (790 mg, 3.12 mmol) in DCM (20 ml), acetonitrile (8 ml) and water (8 ml), at O0C was added NaIO4 (867 mg, 4.05 mmol) followed by RuO2 (2mg). The reaction mixture was stirred at O0C for 2h. Water was added and the phases were separated and the aqueous phase was extract with ethyl acetate. The organic layers were combined washed with brine, dried (MgSO4), and concentrated in vacuo. The residue was then purified by flash column chromatography to give the desired product (640 mg, 76%) as an off white solid. MS (ISP) 287.0 (M+NH4)+.
d) Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-trifluoromethylpyrazol-l-yl)-ethyl]- amine and (4-?e/t-butylbenzyl)-[2-(4-chloro-5-trifluoromethylpyrazol-l-yl)-ethyl]-amine: To a suspension of NaH (67 mg, 1.67 mmol) in THF (10 ml) at O0C was added a solution of 4-chloro-3-trifluoromethyl-lH-pyrazole (190 mg, 1.11 mmol) in TΗF (5 ml) dropwise. The reaction mixture was stirred at O0C for 30 min and then 3-(4-tøt-butylbenzyl)- [ 1,2,3] oxathiazolidine 2,2-dioxide (300 mg, 1.11 mmol) was added portion wise. The reaction mixture was warmed to RT and stirred for a further 3h after which the reaction mixture was quenched with 5ml 20% (v/v) H2SO4. The reaction mixture was warmed to 6O0C overnight and then cooled to RT and poured into water. The aqueous phase was made basic with IN NaOH and then extracted with ethyl acetate. The organic layers were combined, washed with brine, dried over MgSO4, filtered and concentrated in vacuo to give a 4:1 mixture of regioisomers (4-?e/t-butylbenzyl)-[2-(4-chloro-3-trifluoromethylpyrazol- l-yl)-ethyl] -amine (210 mg, 52%) MS (ISP) 360.1 (M+H)+ and (4-tøf-butylbenzyl)-[2-(4- chloro-5-trifluoromethylpyrazol-l-yl)-ethyl] -amine (50 mg, 13%) MS (ISP) 360.1 (M+H)+ respectively which were separated by flash column chromatography.
Example S6-C: Preparation of (4-?e/t-butylbenzyl)-[2-(3-cyclopropylphenyl)-ethyl]- amine
To a solution of m-bromophenylcyclopropane (synthesized as described in J.Org.Chem. 1976, 41, 2262-2266) (100 mg, 0.51 mmol) in dry THF (3 ml) at -780C was added nBuIi (317 μl, 1.6M solution in hexane, 0.51 mmol) dropwise. The reaction mixture was stirred at -780C for 10 min and then a solution of 3-(4-tøt-butylbenzyl)-[l,2,3]oxathiazolidine 2,2-dioxide ( 109mg, 0.41mmol) in THF ( ImI) was added dropwise. The reaction mixture was warmed to O0C over 3 hours and then quenched with 5ml 20% (v/v) H2SO4. The reaction mixture was warmed to 6O0C overnight and then cooled to RT and poured into water. The aqueous phase was made basic with IN NaOH and then extracted with ethyl
acetate. The organic layers were combined, washed with brine, dried over MgSO4, filtered and concentrated in vacuo to give a crude residue which was purified by flash column chromatography to give (4-tøf-butylbenzyl)-[2-(3-cyclopropylphenyl)-ethyl]-amine (72mg, 58%) as a colourless oil. MS (ISP) 308.4 (M+H)+.
Example S7-C: Preparation of (4-?e/t-butylbenzyl)-[2-(3-chloro-5-cyclopropylphenyl)- ethyl] -amine
a) Preparation of l-bromo-S-chloro-S-cyclopropylbenzene:
To a solution of l,3-dibromo-5-chlorobenzene (500 mg, 1.85 mmol) in THF (1 ml) was added cyclopropylmagnesium bromide (3698 μl, 0.5M solution in THF, 1.85 mmol) in a sealed tube and the reaction mixture was degassed with argon for 5 min before tetrakis- (triphenylphosphine)palladium (0) (107 mg, 0.09 mmol) was added. The resulting solution was heated to 7O0C overnight, cooled to RT and then quenched with sat. NH4Cl solution and extracted with pentane. The organic phases were combined, washed with water and brine, dried over MgSO4 and filtered through a short pad of silica gel to give the desired product (272 mg, 64%) which did not require further purification. 1H NMR
(CDCl3, 300MHz): 7.28 (aptt, J=2.0Hz, IH), 7.08 (aptt, J= 1.5Hz, IH), 6.97 (aptt, J= 1.5Hz, IH), 1.83 (m, IH), 1.04-0.97 (m, 2H), 0.72-0.67 (m, 2H).
b) Preparation of (4-?e/t-butylbenzyl)-[2-(3-chloro-5-cyclopropylphenyl)-ethyl] -amine: The title compound was synthesized in analogy to example S6-C using l-bromo-3-chloro- 5-cyclopropylbenzene (96 mg, 0.71 mmol) and 3-(4-tøt-butylbenzyl)-[l,2,3]oxathiazol- idine 2,2-dioxide (36 mg, 0.89 mmol). The residue was purified by flash column chromatography to give the desired product ( 155 mg, 39%) as a colourless oil. MS (ISP) 342.2 (M+H)+.
Example S8-C: Preparation of (4-?e/t-butylbenzyl)-[2-(3-cyclopropyl-4-fluorophenyl)- ethyl] -amine
a) Preparation of 3-cyclopropyl-4-fluorophenylamine:
To a solution of 3-bromo-4-fluorophenylamine (synthesized as described in J.Org.Chem. 1981, 46, 2280-2286) (415 mg, 2.18 mmol), cyclopropyl boronic acid (244 mg, 2.84 mmol), potassium phosphate (1.62 g, 7.64 mmol), and tricyclohexyl phosphine (61 mg, 0.22 mmol) in toluene (10 ml) and water (0.5 ml) was added palladium acetate (25 mg, 0.11 mmol) and the reaction mixture was heated to 1000C overnight. The mixture was then cooled to RT and diluted with water and extracted with ether. The organic phases were
combined, washed with brine, dried (MgSO4), filtered and concentrated in vacuo to give a residue which was purified by flash column chromatography to give 3-cyclopropyl-4- fluorophenylamine (210 mg, 64%). MS (ISP) 152.2 (M+H)+.
b) Preparation of 2-cyclopropyl-l-fluoro-4-iodobenzene: To a solution of 3-cyclopropyl-4-fluorophenylamine (210 mg, 1.39 mmol) in DME (1.5 ml) was added caesium iodide (360 mg, 1.39 mmol), cuprous iodide (82 mg, 0.43 mmol), iodine (176 mg, 0.70 mmol) and isoamyl nitrite (1.11 ml, 8.34 mmol). The reaction mixture was heated to 6O0C for 2 h. The reaction mixture was cooled to RT and partitioned between pentane and sat. NH4Cl solution. The organic layer was separated, washed with 5% sodium thiosulfite and brine, dried (MgSO4), filtered and concentrated in vacuo to give a residue which was purified by flash column chromatography ( 100% pentane) to yield the desired 2-cyclopropyl-l-fluoro-4-iodobenzene (262 mg, 72%) as a colourless oil. 1H NMR (CDCl3, 300MHz): 7.40 (m, IH), 7.17 (m, IH), 6.76 (m, IH), 2.02 (m, IH), 1.03-0.96 (m, 2H), 0.74-0.68 (m, 2H).
c) Preparation of (4-?e/t-butylbenzyl)-[2-(3-cyclopropyl-4-fluorophenyl)-ethyl] -amine: The title compound was synthesized in analogy to example S6-C using 2-cyclopropyl- 1- fluoro-4-iodobenzene (100 mg, 0.38 mmol) and 3-(4-tert-butylbenzyl)-[l,2,3]oxathiazol- idine 2,2-dioxide (103 mg, 0.38 mmol) . The residue was purified by flash column chromatography to give the desired product (35 mg, 28%) as a colourless oil. MS (ISP) 326.3 (M+H)+.
Example S9-C: Preparation of [2-(4-fluoro-phenyl)-ethyl]-(4-pentafluoroethyl-benzyl)- amine (S9-C1)
a) Preparation of N-[2-(4-fluoro-phenyl)-ethyl]-4-pentafluoroethyl-benzamide A solution of 4-pentafluoroethyl-benzoic acid (500 mg, 2.08 mmol), 2- (4- fluorophenyl) - ethylamine (319 mg, 2.29 mmol), 4-methylmorpholine (632 mg, 6.24 mmol), and HBTU (1.19 g, 3.12 mmol) in DMF (38 mL) was stirred at RT for 16 h, then the reaction mixture was partitioned between water and ethyl acetate. The organic layer was washed with brine, dried (MgSO4), and evaporated. Chromatography (SiO2, heptane-ethyl acetate gradient) afforded the title compound (746 mg, 99%). White solid, MS (ISP) 362.2 (M+H)+.
b) Preparation of [2-(4-fluoro-phenyl)-ethyl]-(4-pentafluoroethyl-benzyl)-amine
Borane-tetrahydrofuran complex solution ( 1 M in THF, 6.5 mL, 6.5 mmol) was added at O0C to a solution of N-[2-(4-fluoro-phenyl)-ethyl]-4-pentafluoroethyl-benzamide (740
mg, 2.04 mmol) in THF (8 niL), and the homogeneous solution was heated at reflux over 3 h. After cooling, excess reagent was destroyed by careful addition of methanol at O0C. Volatile material was removed by distillation, then the residue was dissolved in 5% ethanolic sulfuric acid solution (5 mL). The solution was refluxed for 90 min, then partitioned between 2 M aq. sodium hydroxide solution and ethyl acetate. The organic layer was washed with brine, dried (MgSO4), and evaporated. Chromatography (SiO2, DCM/- methanol/NH4OH 95:5:0.1) afforded the title compound (652 mg, 92%). Colourless oil, MS (ISP) 348.2 (M+H)+.
¥: Prepared in analogy to example
Example SlO-C: Preparation of (4-tert-butyl-benzyl)-[2-(3-ethyl-phenyl)-ethyl]-amine
a) Preparation of [2-(3-bromo-phenyl)-ethyl]-(4-tert-butyl-benzyl)-carbamic acid tert- butyl ester:
To a solution of [2-(3-bromo-phenyl)-ethyl]-(4-tert-butyl-benzyl)-amine (3544 mg, 10.23 mmol) in DCM (30 ml) was added di-tert-butyl-dicarbonate (2507 mg, 11.3 mmol) at O0C. The reaction mixture was stirred for 30 min at O0C and then at RT over night. Saturated NH4Cl solution was added and the mixture was extracted with DCM. The combined organic extracts were washed with 10% KHCO3 solution and brine and were dried (Na2SO4). After evaporation of the solvent the crude title compound (4722 mg) was ob- tained as a colorless oil. MS (ISP) 446.4 (M+H)+. b) Preparation of (4-tert-butyl-benzyl)-[2-(3-trimethylsilanylethynyl-phenyl)-ethyl]-carb- amic acid tert-butyl ester:
A mixture of the crude [2-(3-bromo-phenyl)-ethyl]-(4-tert-butyl-benzyl)-carbamic acid tert-butyl ester (515 mg, 1.154 mmol), bis(triphenylphosphine)palladium(II)chloride (32 mg, 0.0461 mmol), CuI (11 mg, 0.0577 mmol) and (trimethylsilyl) acetylene (251 μl, 1.73 mmol) in triethylamine (3.4 ml) was heated in a sealed tube at 1050C over night. The mixture was then cooled to RT, diluted with sat. NaHCO3- solution and extracted three times with ethyl acetate. The combined ethyl acetate layers were then washed with water and brine and were dried (Na2SO4) and evaporated. The remaining residue was purified by chromatography (heptane/EtOAc 100:0 to 95:5) to obtain the title compound as a yellow gum (441 mg, 82%). MS (ISP) 464.4 (M+H)+. c) Preparation of (4-tert-butyl-benzyl)-[2-(3-ethynyl-phenyl)-ethyl]-carbamic acid tert- butyl ester:
To a solution of (4-tert-butyl-benzyl)-[2-(3-trimethylsilanylethynyl-phenyl)-ethyl]-carb- amic acid tert-butyl ester (440 mg, 0.949 mmol) in THF (7.6 ml) was added a 1 molar solution of TBAF in THF (949 μl, 0.949 mmol) at -780C. After 15 min at -780C the solution was allowed to warm to O0C for 30 min. Then brine was added and the mixture was extracted with ether. The combined ether layers were dried (Na2SO4) and evaporated and the remaining residue was purified by chromatography (pentane/ether 100:0 to 90:10) to obtain the title compound as a colorless oil (314 mg, 84%). MS (ISP) 392.3 (M+H)+. d) Preparation of (4-tert-butyl-benzyl)-[2-(3-ethyl-phenyl)-ethyl]-carbamic acid tert-butyl ester:
A solution of (4-tert-butyl-benzyl)-[2-(3-ethynyl-phenyl)-ethyl]-carbamic acid tert-butyl ester (149 mg, 0.381 mmol) in methanol (12 ml) was stirred at RT under an atmosphere of
hydrogen in the presence of a catalytic amount of palladium on charcoal (5%) for 2 days. The reaction mixture was then filtered and evaporated and the remaining residue was purified by chromatography (heptane/EtOAc 100:0 to 95:5) to obtain the title compound as a colorless oil (73 mg, 48%). MS (ISP) 396.4 (M+H)+. e) Preparation of (4-tert-butyl-benzyl)-[2-(3-ethyl-phenyl)-ethyl]-amine:
To a solution of (4-tert-butyl-benzyl)-[2-(3-ethyl-phenyl)-ethyl]-carbamic acid tert-butyl ester 66 mg, 0.166 mmol) in DCM (1 ml) was added triflu or o acetic acid (128 μl, 1.668 mmol) at O0C. The reaction mixture was allowed to warm to RT and was stirred over night. The mixture was then basified with 1 N NaOH and extracted with DCM. The combined extracts were dried (Na2SO4) and evaporated to obtain the title compound as a colorless gum (45 mg, 92%). MS (ISP) 296.5 (M+H)+.
Example SIl-C: Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-cyclopropylphenyl)- ethyl] -amine and (4-?e/t-butylbenzyl)-[2-(3,4-dicyclopropylphenyl)- ethyl] -amine
The title compounds were synthesized in analogy to 3-cyclopropyl-4-fluorophenylamine (step a, example S8-C) using [2-(3-bromo-4-chlorophenyl)-ethyi]-(4-tøt-butylbenzyl)- amine (128 mg, 0.34 mmol) and cyclopropyl boronic acid (72 mg, 0.84 mmol). The residue was purified by flash column chromatography to give an unseperable 1:4 mixture of products (4-?e/t-butylbenzyl)-[2-(4-chloro-3-cyclopropylphenyl)-ethyl]-amine (13 mg, 11%), MS (ISP) 342.2 (M+H)+ and (4-tøt-butylbenzyl)-[2-(3,4-dicyclopropylphenyl)- ethyl] -amine (55 mg, 47%), MS (ISP) 348.4 (M+H)+ which was reacted on without further purification.
Example S12-C: Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-isopropylphenyl)- ethyl] -amine
a) Preparation of 2-(5-bromo-2-chlorophenyl)-propan-2-ol:
To a solution of 5-bromo-2-chlorobenzoic acid methyl ester ( 1 g, 4 mmol, leq) in THF (20 ml) at -780C was added a 3M solution of methyl magnesiumbromide (4 ml, 12 mmol, 3eq) in THF dropwise. The reaction mixture was then warmed to RT and stirred overnight. The mixture was poured into sat. ammonium chloride solution and extracted with ether. The organic layers were combined, washed with brine, dried (MgSO4), filtered and concentrated in vacuo to give a residue which was purified by flash column chromatography (0 to 20% ether in pentane) to give the desired product as a colorless oil (980 mg, 98%).
b) Preparation of 4-bromo-l-chloro-2-isopropenylbenzene:
To a solution of 2-(5-bromo-2-chlorophenyl)-propan-2-ol (500 mg, 2 mmol, leq) in toluene (5 ml) was added a catalytic amount ofp-toluenesulfonic acid (38 mg, 0.2 mmol, O.leq) and the solution was refluxed under a Dean-Stark H2O separator overnight. The reaction mixture was allowed to cool to RT and was diluted with ether. The mixture was washed with sat. NaHCO3- solution and brine, dried (MgSO4), filtered and concentrated in vacuo to give the desired product (357 mg, 77%) as a colorless oil which did not require further purification. c) Preparation of 4-bromo-l-chloro-2-isopropylbenzene: A mixture of 4-bromo-l-chloro-2-isopropenylbenzene (357 mg, 1.54 mmol, leq) and PtO2 (35 mg, 0.15 mmol, O.leq) in 4 ml toluene was stirred under an atmosphere of hydrogen at RT overnight. The reaction mixture was then filtered through celite®and the filtrate was evaporated to dryness to give the desired product (260 mg, 72%).1H NMR (CDCl3, 300 MHz): 7.39 (d, J=2 Hz, IH), 7.26-7.16 (m, 2H), 3.35 (sept, J=7 Hz, IH), 1.23 (d, J=7 Hz, 6H). d) Preparation of (4-?e/t-butylbenzyl)-[2-(4-chloro-3-isopropylphenyl)-ethyl]-amine: The title compound was synthesized in analogy to example S6-C using 4-bromo- 1-chloro- 2-isopropylbenzene (120 mg, 0.51 mmol), and 3-(4-tøt-butylbenzyl)-[l,2,3]oxathiazoli- dine 2, 2-dioxide (138 mg, 0.51 mmol). The residue was purified by flash column chroma- tography to give the desired product (74 mg, 42%) as a light yellow oil. MS (ISP) 344.3 (M+H)+.
Acids (Compounds of formula II):
Example Sl-D: Preparation of 2-chloro-6-trifluoromethyl-isonicotinic acid
a) Preparation of 6-chloro-3-iodo-2-trifluoromethyl-pyridine: To a stirred solution of 7.1 ml of n-BuIi (1.6M in hexane, 11.3 mmol) in 7 ml THF under argon at -730C were added 1.6 ml of diisopropylamine (11.3 mmol) in 3 ml THF within 8 min. After 10 min stirring at the same temperature a solution of 1 g of 2-chloro-6-(tri- fluoromethyl) -pyridine (5.51 mmol) in 5 ml THF was added within 15 min (temperature between -76 and -750C). The dark brown solution was stirred at -750C for 1 h 15 min. Finally a solution of 1.4 g of iodine (5.51 mmol) in 10 ml THF was added at -750C over 25 min. After additional 45 min stirring at the same temperature 12 ml 2M aqueous HCl were added within 2 min (temperature raised from -78 to -5O0C. The cooling device was then removed, the reaction mixture diluted with diethylether. After separation of the organic
phase, the aqueous phase was reextracted with diethylether. The combined organic phases were successively washed with 10 ml IM sodiumthiosulfate, saturated NaHCO3 and brine, dried over magnesium sulfate, filtered off and concentrated in vacuo to yield 1.54 (69 %) of ό-chloro-S-iodo-l-trifluoromethyl-pyridine as a brown semisolid residue. MS: 307.0
b) Preparation of 2-chloro-4-iodo-6-trifluoromethyl-pyridine:
To a stirred solution of 3.05 mlof n-BuIi (1.6 M in hexane, 4.88 mmol) under argon at -750C was added 0.69 ml of diisopropylamine (4.88 mmol) in 2.5 ml THF over 5 min (temperature between -72 and -750C). After 10 min at -750C a solution of 1.5 g of 6-chloro-3-iodo-2-trifluoromethyl-pyridine (4.88 mmol) in 3.5 ml THF was added drop- wise over 20 min at the same temperature. After 1.5 hours stirring at -750C, 6 ml 2M aqueous HCl were added (temperature was allowed to raise to RT). The mixture was then diluted with water, extracted with diethylether and the combined organic phases were successively washed with saturated NaHCO3 solution and brine, dried over magnesium sulfate, filtered off and concentrated in vacuo. The residue was purified by silicagel chro- matography (eluent: heptane / AcOEt 95:5) leading to 1.145 g (69 %) of 2-chloro-4-iodo- 6-trifluoromethyl-pyridine as a white powder. MS: 307.0
c) Preparation of 2-chloro-6-trifluoromethyl-isonicotinic acid:
To a stirred solution of 1.1 g of 2-chloro-4-iodo-6-trifluoromethyl-pyridine (3.58 mmol) in 15 ml THF under argon at -750C, were added 2.2 ml of n-BuIi (1.6 M in hexane) within 15 min (temperature kept between -720C and -750C). After 5 additional min stirring at -750C, the reaction mixture was poured on an excess of freshly crushed dry ice and stirred until RT was reached. The reaction mixture was then concentrated in vacuo, the remaining residue treated with 2M aqueous HCl and the resulting mixture was extrated with diethylether. The combined organic phases were washed with water, and then extracted with saturated NaHCO3 solution. The aqueous phase was then acidified with concentrated HCl, extracted twice with diethylether and the combined organic phases were washed with brine, dried over magnesium sulfate, filtered and concentrated in vacuo. The remaining residue was recrystalized from 12 ml hot n-hexane, leading to 0.459 g (56 %) of 2-chloro- 6-trifluoromethyl-isonicotinic acid as an off-white solid. MS: 224.0 (M-H)".
Example S2-D: Preparation of 3-chloro-4-fluoro-5-trifluoromethyl-benzoic acid
To a stirred solution of 2.03 ml of sec-BuIi (1.3M in cyclohexane, 2.64 mmol) and 0.4 ml of TMEDA under argon at -9O0C was added a solution of 0.25 g of 4-fluoro-3-trifluoro- methyl-benzoic acid (1.2 mmol) in 8 ml THF over 20 min (temperature kept between -
920C and -880C). After 30 min stirring at the same temperature, the initially light orange suspension turned brown. A solution of 1.14 g of hexachloroethane (4.82 mmol) in 10 ml THF was then added within 2 min (temperature raised to -620C). The reaction mixture was then left to warm slowly to RT ( 1 hour) and treated carefully with 2 ml water. The reaction mixture was then concentrated in vacuo, diluted with water and extracted with diethyl- ether. The aqueous phase was then acidified with concentrated HCl and extrated twice with ethylacetate. The combined ethylacetate phases were subsequently washed with water (3x) and brine (Ix), dried over magnesium sulfate, filtered and concentrated in vacuo to yield 0.28 g of a residue which was purified by silicagel chromatography (eluent heptane / AcOEt 90:10 to 75:25) to yield 22 mg of 3-chloro-4-fluoro-5-trifluoromethyl-benzoic acid as a light yellow solid. MS: 241.1 (M-H)".
Example S3-D: Preparation of 3-chloro-5-cyclopropylbenzoic acid:
To a solution of l-bromo-3-chloro-5-cyclopropylbenzene (300 mg, 1.30 mmol) at -780C in THF (5 ml) was added πBuIi (890μl, 1.6M solution in hexane, 1.43 mmol) dropwise. The resulting solution was stirred at -780C for 10 min after which solid carbon dioxide was added and the reaction mixture was warmed to RT over 3 hours. The reaction mixture was quenched with water and then extracted with ether. The aqueous phase was then made acidic with IN HCl and then extracted with ethyl acetate. The organic phases were combined, washed with brine, dried (MgSO4), filtered and concentrated in vacuo to give the desired product 3-chloro-5-cyclopropylbenzoic acid ( 178 mg, 70%) which did not require further purification. MS (ISP) 195.1 (M-H)".
Example S4-D: Preparation of 6-chloro-4-trifluoromethyl-pyridine-2-carboxylic acid:
To a solution of 300 mg of 2-chloro-6-methyl-4-(trifluoromethyl)-pyridine (1.49 mmol) in pyridine (5 ml) was added a solution of 1.61 g of tetrabutylammonium permanganate (4.46 mmol) in pyridine (4.5 ml) and the reaction mixture was stirred at 8O0C for 3 h. The reaction mixture was then poured into a mixture of water and ice and then NaHSO3 solution (40% in water) was added until the color turned light yellow. The mixture was then acidified by addition of 2N HCl and extracted with ethyl acetate. The combined organic layers were then washed with IN HCl and brine, dried (Na2SO4), filtered and concentrated. The remaining residue was purified by chromatography (DCM / MeOH 100:0 to 90:10) to yield 224 mg (67%) of a gray liquid. MS (ISP) 224.3 (M-H)".
Example S5-D: Preparation of 6-Methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid
a) Preparation of 6-methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid ethyl ester: 2.241 g (20 mmol) of 2,2,2- trifluoro-acetamidine were dissolved in 80 ml ethanol and treated with 3.163 g (20 mmol) of 2,4-dioxo-pentanoic acid ethyl ester. The resulting solution was cooled to 0-5 0C and treated with 120 ml of HCl- saturated ethanol. The reaction mixture was allowed to warm-up to RT and stirred for additional 3 hours. The mixture was then added drop wise under cooling to 800 ml saturated NaHCO3 solution. The resulting mixture was then extracted twice with 300 ml DCM and the combined organic phases were dried over magnesium sulfate, filtered and concentrated in vacuo to yield 3.1 g of a yellow oil. This residue was then purified by silicagel chromatography (eluent: heptane / ethyl acetate 100:0 to 30:70) leading to a colorless oil which crystallized spontaneously, leading to 1.3 g of 6-methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid ethyl ester.
b) Preparation of 6-methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid:
1.3 g (5.551 mmol) of 6-methyl-2-trifluoromethyl-pyrimidine-4-carboxylic acid ethyl ester were dissolved in 30 ml dioxane and treated with 11.1 ml (11.1 mmol) 1 N NaOH and stirred for 2 hours at RT. The reaction mixture was then treated with 11.1 ml (11.1 mmol) 1 N HCl and concentrated in vacuo. The resulting solid residue was then suspended in DCM-methanol, filtered-off, washed with additional DCM-methanol and the combined organic phases were then concentrated in vacuo, to yield 1.1 g (96 %) of 6- methyl- 2- tri- fluoromethyl-pyrimidine-4-carboxylic acid. MS: 205.1 (M-H)".
Compounds of formula I:
Example 1: Preparation of N-(4-tert-butyl-benzyl)-3-chloro-N-[2-(4-chloro-phenyl)- ethyl]-2-fluoro-5-trifluoromethyl-benzamide (Bl)
To a solution of 50 mg of 3-chloro-2-fluoro-5-trifluoromethyl-benzoic acid (0.206 mmol) and 68 mg (0.225 mmol) of (4-tert-butylbenzyl)-[2-(4-chlorophenyl)-ethyi]-amine in 3 ml of DMF were added 117 mg of HBTU (0.31 mmol) and 0.063 ml (0.62 mmol) of 4-methyl- morpholine. After stirring the reaction mixture over night at RT it was poured on a mixture of 15 ml of brine and 15 ml of water and extracted with ethyl acetate. The combined organic phases were washed with brine, dried with magnesium sulfate, filtered and concentrated in vacuo. The residue was purified by column chromatography (silica gel; heptane/ - EtOAc 95:5) to give 76 mg (70 %) of a light yellow amorphous material. MS (ISP) 526.0 (M+H)+.
In analogy to example 1:
Example 2: N-(4-tert-butyl-benzyl)-3-chloro-2-fluoro-N-[2-(3-hydroxy-phenyl)- ethyl]-5-trifluoromethyl-benzamide
a) Preparation of N-[2-(3-benzyloxy-phenyl)-ethyi]-N-(4-tert-butyl-benzyl)-3-chloro-2- fluoro-5-trifluoromethyl-benzamide:
The title compound was prepared in analogy to Example 1, using [2-(3-benzyloxy-phenyl)- ethyl]-(4-tert-butyl-benzyl)-amine (S9-C43) and 3-chloro-2-fluoro-5-(trifluoromethyl)- benzoic acid . MS: 597.3 [ISP (M+H)+] . b) Preparation of N-(4-tert-butyl-benzyl)-3-chloro-2-fluoro-N-[2-(3-hydroxy-phenyl)- ethyl] -5-trifluoromethyl-benzamide:
A solution of 1.1 g of N-[2-(3-benzyloxy-phenyl)-ethyl]-N-(4-tert-butyl-benzyl)-3-chloro- 2-fluoro-5-trifluoromethyl-benzamide (1.84 mmol) in 50 ml ethyl acetate was hydro- genated over 0.33 g Pd/C-5%. After completion of the reaction the suspension was filtered off and concentrated in vacuo to give 0.75 g of a colorless amorphous material. MS: 508.4 [ISP (M+H)+] .
Example 3: N-(4-tert-butyl-benzyl)-3-chloro-5-ethyl-N-[2-(3-fluoro-5-trifluoro- methyl-phenyl)-ethyl] -benzamide
285 mg of 3-bromo-N-(4-tert-butyl-benzyl)-5-chloro-N-[2-(3-fluoro-5-trifluoromethyl- phenyl) -ethyl] -benzamide (0.6 mmol, Example B177), 44 mg of ethylboronic acid (1.75 mmol), 371 mg of tri-potassiumphosphate (0.05 mmol), 14 mg of tricyclohexylphosphine and 6 mg of palladium acetate were suspended in 2.3 ml toluene and 0.1 ml water and stirred at 1000C for 3.5 h under nitrogen. The reaction mixture was then cooled down to RT, diluted with 4 ml water and extracted twice with ethylacetate. The combined organic
layers were washed with brine, dried over magnesium sulfate, filtered off and concentrated under vacuo. The resulting residue was purified by flash column chromatography (Heptane / AcOEt: 95/5) to yield 192 mg of a yellow solid. MS (ISP) 520.3 (M+H)+.
Example 3-b: N-(4-tert-butyl-benzyl)-3-chloro-5-ethyl-N-[2-(3-trifluoromethyl-phenyl)- ethyl] -benzamide
The title compound was prepared in analogy to Example 3, using 3-bromo-N-(4-tert- butyl-benzyl)-5-chloro-N-[2-(3-trifluoromethyl-phenyl)-ethyl] -benzamide (Example B176). MS (ISP) 502.3 (M+H)+.
Example 3-c: N-(4-tert-butyl-benzyl)-3-ethyl-2-fluoro-N-[2-(3-fluoro-5-trifluoro- methyl-phenyl)-ethyl]-5-trifluoromethyl-benzamide
The title compound was prepared in analogy to example 3, using N-(4-tert-butyl-benzyl)- 3-chloro-2-fluoro-N-[2-(3-fluoro-5-trifluoromethyl-phenyl)-ethyl]-5-trifluoromethyl- benzamide (Example B63). MS (ISP) 572.3 (M+H)+.
Example 3-d: N-(4-tert-butyl-benzyl)-2-fluoro-N-[2-(3-fluoro-5-trifluoromethyl- phenyl)-ethyl]-5-trifluoromethyl-benzamide
The title compound was prepared in analogy to example 3, using N-(4-tert-butyl-benzyl)- 3-chloro-2-fluoro-N-[2-(3-fluoro-5-trifluoromethyl-phenyl)-ethyl]-5-trifluoromethyl- benzamide (Example B63). 544.2 [ISP (M+H)+]
Example 3-e: N-(4-tert-butyl-benzyl)-3-chloro-5-propyl-N-[2-(3-trifluoromethyl- phenyl)-ethyl] -benzamide
The title compound was prepared in analogy to example 3, using 3-bromo-N-(4-tert- butyl-benzyl)-5-chloro-N-[2-(3-trifluoromethyl-phenyl)-ethyl] -benzamide (Example B176) and n-propylboronic acid. 516.2 [ISP (M+H)+]
Example 3-f: N-(4-tert-butyl-benzyl)-3-chloro-N-[2-(3-fluoro-5-trifluoromethyl- phenyl)-ethyl]-5-propyl-benzamide
The title compound was prepared in analogy to example 3, using 3-bromo-N-(4-tert- butyl-benzyl)-5-chloro-N-[2-(3-fluoro-5-trifluoromethyl-phenyl)-ethyl] -benzamide (Example B177) and n-propylboronic acid. 534.3 [ISP (M+H)+]
Example 3-g: N-(4-tert-butyl-benzyl)-3-chloro-N-[2-(3-ethyl-4-fluoro-phenyl)-ethyl]-2- fluoro-5-trifluoromethyl-benzamide
The title compound was prepared in analogy to example 3, using N-[2-(3-bromo-4-fluoro- phenyl)-ethyl]-N-(4-tert-butyl-benzyl)-3-chloro-2-fluoro-5-trifluoromethyl-benzamide (Example B178) and ethylboronic acid. 538.3 [ISP (M+H)+]
Example 3-h: N-(4-tert-butyl-benzyl)-3-chloro-2-fluoro-N-[2-(4-fluoro-3-propyl- phenyl)-ethyl]-5-trifluoromethyl-benzamide
The title compound was prepared in analogy to example 3, using N-[2-(3-bromo-4-fluoro- phenyl)-ethyl]-N-(4-tert-butyl-benzyl)-3-chloro-2-fluoro-5-trifluoromethyl-benzamide (Example B178) and n-propylboronic acid. 552.2 [ISP (M+H)+]
Example 4: N-(4-tert-butyl-benzyl)-N-[2-(3-tert-butyl-4-hydroxy-phenyl)-ethyl]-3- chloro-2-fluoro-5-trifluoromethyl-benzamide
a) Preparation of N-[2-(4-benzyloxy-3-tert-butyl-phenyl)-ethyl]-N-(4-tert-butyl-benzyl)- 3-chloro-2-fluoro-5-trifluoromethyl-benzamide: The title compound was prepared in analogy to Example 1, using [2-(4-benzyloxy-3-tert- butyl-phenyl)-ethyl]-(4-tert-butyl-benzyl)-amine (S9-C48) and 3-chloro-2-fluoro-5-(tri- fluoromethyl)benzoic acid . MS: 654.4 [ISP (M+H)+] . b) Preparation of N-(4-tert-butyl-benzyl)-N-[2-(3-tert-butyl-4-hydroxy-phenyl)-ethyl]-3- chloro-2-fluoro-5-trifluoromethyl-benzamide: A solution of 182 mg of N-[2-(4-benzyloxy-3-tert-butyl-phenyl)-ethyl]-N-(4-tert-butyl- benzyl)-3-chloro-2-fluoro-5-trifluoromethyl-benzamide (0.278 mmol) in 15 ml ethyl acetate were hydrogenated over 100 mg Pd/C-5%. After completion of the reaction the suspension was filtered off and concentrated in vacuo. The resulting residue was purified by flash column chromatography (Heptane / AcOEt: 90/10) to yield 130 mg of a colourless viscous oil. MS (ISP) 564 (M+H)+.
The compounds of formula I are cholesteryl ester transfer protein (CETP) inhibitors.
Atherosclerosis and its associated coronary heart disease is the leading cause of death in the industrialized world. Risk for development of coronary heart disease has been shown to be strongly correlated with certain plasma lipid levels. Lipids are transported in the blood by lipoproteins. The general structure of lipoproteins is a core of neutral lipids (triglyceride and cholesterol ester) and an envelope of polar lipids (phospholipids and non esterified
cholesterol). There are three different classes of plasma lipoproteins with different core lipid content: the low density lipoprotein (LDL) which is cholesteryl ester (CE) rich; high density lipoprotein (HDL) which is also cholesteryl ester (CE) rich; and the very low density lipoprotein (VLDL) which is triglyceride (TG) rich. The different lipoproteins can be separated based on their different flotation density or size.
High LDL-cholesterol (LDL-C) and triglyceride levels are positively correlated, while high levels of HDL-cholesterol (HDL-C) are negatively correlated with the risk for developing cardiovascular diseases.
Plasma lipoprotein metabolism can be described as a flux of cholesterol between liver and the other tissues. The LDL pathway corresponds to the secretion of VLDL from the liver to deliver cholesterol by LDL to tissues. Any alteration in LDL catabolism could lead to uptake of excess cholesterol in the vessel wall forming foam cells and atherosclerosis. The opposite pathway is the mobilization of free cholesterol from peripheral tissues by HDL to deliver cholesterol to the liver to be eventually excreted with bile. In humans a significant part of cholesteryl ester (CE) is transferred from HDL to the VLDL, LDL pathway. This transfer is mediated by a 70,000 dalton plasma glycoprotein, the cholesteryl ester transfer protein (CETP).
Mutations in the CETP gene associated with CETP deficiency are characterized by high HDL-cholesterol levels (>60 mg/dL) and reduced cardiovascular risk. Such findings are consistent with studies of pharmacologically mediated inhibition of CETP in the rabbit, which argue strongly in favor of CETP inhibition as a valid therapeutic approach [Le Goff et al., Pharmacology & Therapeutics 101:17-38 (2004); Okamoto et al., Nature 406:203-207 2000)] .
No wholly satisfactory HDL-elevating therapies exist. Niacin can significantly increase HDL, but has serious toleration issues which reduce compliance. Fibrates and the HMG CoA reductase inhibitors raise HDL-cholesterol only modestly (-10- 12%) . As a result, there is a significant unmet medical need for a well tolerated agent which can significantly elevate plasma HDL levels. The net result of CETP activity is a lowering of HDL-C and an increase in LDL-C. This effect on lipoprotein profile is believed to be pro-atherogenic, especially in subjects whose lipid profile constitutes an increased risk for coronary heart disease. Therefore by inhibiting CETP activity there is the potential to inverse this relationship towards a lower risk and ultimately to protect against coronary heart diseases and associated mortality.
Thus, CETP inhibitors are useful as medicaments for the treatment and/or prophylaxis of atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbeta-lipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myo- cardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
In addition, CETP inhibitors maybe used in combination with another compound, said compound being an HMG-CoA reductase inhibitor, a microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion- exchange resin, an antioxidant, an ACAT inhibitor or a bile acid sequestrant.
As described above, the compounds of formula I of the present invention can be used as medicaments for the treatment and/or prophylaxis of diseases which are mediated by CETP. Examples of such diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia. The use as medicament for the treatment and/or prevention of dyslipidemia is preferred.
The invention therefore also relates to pharmaceutical compositions comprising a compound as defined above and a pharmaceutically acceptable carrier and/or adjuvant.
Further, the invention relates to compounds as defined above for use as therapeutically active substances, particularly as therapeutic active substances for the treatment and/or prophylaxis of diseases which are mediated by CETP. Examples of such diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia.
In another embodiment, the invention relates to a method for the treatment and/or prophylaxis of diseases which are mediated by CETP. Examples of such diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypo-
alphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia. A method for the treatment and/or prophy- laxis of dyslipidemia is preferred.
The invention further relates to the use of compounds of formula I as defined above for the treatment and/or prophylaxis of diseases are mediated by CETP. Examples of such diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia. The use of compounds of formula I as defined above for the treatment and/or prophylaxis of dyslipidemia is preferred.
In addition, the invention relates to the use of compounds of formula I as defined above for the preparation of medicaments for the treatment and/or prophylaxis of diseases are mediated by CETP. Examples of such diseases are atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular dis- orders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia. The use of compounds of formula I as defined above for the preparation of medicaments for the treatment and/or prophylaxis of dyslipidemia is preferred.
In addition, CETP inhibitors are useful in combination with another compound, said compound being an HMG-CoA reductase inhibitor, an microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion- exchange resin, an antioxidant, an ACAT inhibitor or a bile acid sequestrant.
The invention therefore also relates to pharmaceutical compositions comprising a com- pound of formula I as defined above in combination with an HMG-CoA reductase inhibitor, an microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion-exchange resin, an antioxidant, an ACAT inhi-
bitor or a bile acid sequestrant, as well as a pharmaceutically acceptable carrier and/or adjuvant.
The invention further relates to the use of compounds of formula I as defined above in combination with an HMG-CoA reductase inhibitor, a microsomal triglyceride transfer protein (MTP)/ApoB secretion inhibitor, a PPAR activator, a bile acid reuptake inhibitor, a cholesterol absorption inhibitor, a cholesterol synthesis inhibitor, a fibrate, niacin, an ion- exchange resin, an antioxidant, an ACAT inhibitor or a bile acid sequestrant for the treatment and/or prophylaxis of diseases such as atherosclerosis, peripheral vascular disease, dyslipidemia, hyperbetalipoproteinemia, hypoalphalipoproteinemia, hypercholesterolemia, hypertriglyceridemia, familial hypercholesterolemia, cardiovascular disorders, angina, ischemia, cardiac ischemia, stroke, myocardial infarction, reperfusion injury, angioplastic restenosis, hypertension, and vascular complications of diabetes, obesity or endotoxemia, as well as to the use of such a combination for the preparation of corresponding medicaments.
The compounds of formula I and their pharmaceutically acceptable salts possess valuable pharmacological properties. Specifically, it has been found that the compounds of the present invention are inhibitors of the cholesteryl ester transfer protein (CETP).
The following tests were carried out in order to determine the activity of the compounds of formula I.
Activity of CETP inhibitors was determined using a buffer assay system. Partially purified CETP transferred radiolabeled cholesteryl ester from HDL donor particles to biotin-labeled LDL acceptor particles. The reaction was stopped by addition of streptavidin-coupled scintillation proximity assay (SPA) beads. These beads captured the biotinylated acceptor particles and transferred radioactivity was measured. The assay system was purchased and per- formed according to manufacturer's recommendations (Amersham Biosciences). Inhibitory activity of compounds was determined as percentage of positive control activity containing CETP together with donor and acceptor particles. Serial dilution of compounds was performed in order to determine the IC50 values.
Activity of the compounds was subsequently measured in the presence of plasma using the same assay as described above except that the source of CETP was human lipoprotein- deprived serum (LPDS). Inhibitory activity of compounds was determined as percentage of
positive control activity containing all the assay components except compound. Serial dilution of compounds was performed in order to determine the IC50 values.
Under the latter assay conditions, the compounds of the present invention exhibit IC50 values within the range of about 1 nM to about 100 μM, e.g., of about 1 nM to about 1 μM, e.g., of about 1 nM to about 200 nM. The following table shows measured values for some selected compounds of the present invention.
In vivo activity of the compounds of formula I were determined in hamster using the following protocol: Male golden Syrian hamsters (6- week-old, 100- 130 g) under standard chow diet received compounds in the morning by oral gavage using appropriate vehicle, blood was taken 2 h later by retro-orbital bleeding under isofluran anaesthesia and 7 h later on sacrificed animals. Plasma was separated from blood using low speed centrifugation and CETP activity was measured in plasma using the radioactive CETP activity assay as described above except that diluted plasma replaced LPDS. In vivo CETP inhibition was expressed as CETP activity remaining in the plasma of treated animals as compared to plasma CETP activity of placebo treated animals.
Efficacy of compounds in modulating plasma lipid levels can be determined in hamsters after 7 days of daily administration of compounds. Male hamsters are acclimated for 3-4 days to receive food as a paste made of 10 g chow and 10 g water per day. Compounds are then mixed within this paste and a portion containing the proper amount of compounds is given every morning for 7 days. Alternatively compounds can be given by oral gavage using the proper vehicle. Blood is taken before compound treatment by retro-orbital bleeding and at the end of the treatment on sacrificed animals. Plasma is separated from blood by low speed centrifugation and selected organs are taken (e.g liver, fat, brain, etc.). Effects of compounds on plasma lipid levels are determined by measuring total cholesterol, HDL- cholesterol, LDL-cholesterol and triglyceride using colorimetric enzymatic assays (Roche Diagnostic GmbH, Mannheim, Germany). HDL-C, LDL-C and VLDL-C are e.g., quanti-
fied using size exclusion chromatography on superpose-6 column using SMART™ system (Pharmacia). Lipoprotein distribution is calculated assuming a Gaussian distribution for each peak, using a non-linear, least-squares curve-fitting procedure to calculate the area under the curve. Plasma samples are also used to quantify CETP activity as described above. Compound concentration is also determined in plasma and selected tissues as liver, fat, heart, muscle and brain.
Efficacy of compounds in modulating plasma lipid levels was also determined in cholesterol/fat fed hamsters. The protocol is identical as described above except that animals are fed with chow diet enriched with 10 % (w/w) saturated fat and 0.05 % (w/w) cholesterol. Animals received this high fat diet 2 weeks before starting compound administration and continued this diet throughout the study. The 2 weeks pre-treatment induced an increase in plasma cholesterol and triglyceride levels allowing a better assessment of LDL-C and triglyceride lowering.
Efficacy of compounds in its ability to acutely raise HDL-C can be assessed in cynomolgus monkeys. Animals are fed with standard primate maintenance diet. Compounds are formulated with appropriate vehicle and administered to animals by oral gavage. Blood is taken before and at several time-points after compound administration (usually 30 min, 1 h, 2 h, 4 h, 7 h and 24 h) . Plasma is separated from blood by low speed centrifugation and CETP activity and plasma lipids are quantified. Compound potency and efficacy can be assessed by measuring the HDL-C increase after this single-dose administration. In such pharmacodynamic model the extent together with the kinetics of the pharmacologic effect can be assessed.
The compounds of formula I and their pharmaceutically acceptable salts and esters can be used as medicaments, e.g. in the form of pharmaceutical preparations for enteral, parente- ral or topical administration. They can be administered, e.g., perorally, e.g. in the form of tablets, coated tablets, dragees, hard and soft gelatine capsules, solutions, emulsions or suspensions, rectally, e.g. in the form of suppositories, parenterally, e.g. in the form of injection solutions or infusion solutions, or topically, e.g. in the form of ointments, creams or oils.
The production of the pharmaceutical preparations can be effected in a manner which will be familiar to any person skilled in the art by bringing the described compounds of formula I and their pharmaceutically acceptable, into a galenical administration form to-
gether with suitable, non-toxic, inert, therapeutically compatible solid or liquid carrier materials and, if desired, usual pharmaceutical adjuvants.
Suitable carrier materials are not only inorganic carrier materials, but also organic carrier materials. Thus, e.g., lactose, corn starch or derivatives thereof, talc, stearic acid or its salts can be used as carrier materials for tablets, coated tablets, dragees and hard gelatine capsules. Suitable carrier materials for soft gelatine capsules are, e.g., vegetable oils, waxes, fats and semi- solid and liquid polyols (depending on the nature of the active ingredient no carriers are, however, required in the case of soft gelatine capsules). Suitable carrier materials for the production of solutions and syrups are, e.g., water, polyols, sucrose, invert sugar and the like. Suitable carrier materials for injection solutions are, e.g., water, alcohols, polyols, glycerol and vegetable oils. Suitable carrier materials for suppositories are, e.g., natural or hardened oils, waxes, fats and semi-liquid or liquid polyols. Suitable carrier materials for topical preparations are glycerides, semi-synthetic and synthetic glycerides, hydrogenated oils, liquid waxes, liquid paraffins, liquid fatty alcohols, sterols, polyethylene glycols and cellulose derivatives.
Usual stabilizers, preservatives, wetting and emulsifying agents, consistency- improving agents, flavour-improving agents, salts for varying the osmotic pressure, buffer substances, solubilizers, colorants and masking agents and antioxidants come into consideration as pharmaceutical adjuvants.
The dosage of the compounds of formula I can vary within wide limits depending on the disease to be controlled, the age and the individual condition of the patient and the mode of administration, and will, of course, be fitted to the individual requirements in each particular case. For adult patients a daily dosage of about 1 mg to about 1000 mg, especially about 1 mg to about 100 mg, comes into consideration. Depending on the dosage it is con- venient to administer the daily dosage in several dosage units.
The pharmaceutical preparations conveniently contain about 0.1-500 mg, e.g., 0.5-100 mg, of a compound of formula I.
The following examples serve to illustrate the present invention in more detail. They are, however, not intended to limit its scope in any manner.
Example A: Film coated tablets
The active ingredient is sieved and mixed with microcrystalline cellulose and the mixture is granulated with a solution of polyvinylpyrrolidon in water. The granulate is mixed with sodium starch glycolate and magesiumstearate and compressed to yield kernels of 120 or 350 mg respectively. The kernels are lacquered with an aqueous solution / suspension of the above mentioned film coat.
Example B: Capsules
The components are sieved and mixed and filled into capsules of size 2.
Example C: Injection solutions
Example D: Soft gelatin capsules
The active ingredient is dissolved in a warm melting of the other ingredients and the mixture is filled into soft gelatin capsules of appropriate size. The filled soft gelatin capsules are treated according to the usual procedures.
Claims
1. A compound of formula I
R6 and R7 are independently hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cscycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cgcycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N; Y is CH or N; wherein X and Y are not N at the same time; R12 is hydrogen, Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy;
R5 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo- Ci-C6alkoxy;
R4 is hydrogen, or is Q-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-Cgcycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10 or N; B is CR11 or N; D is CR3 or N; wherein -B=A- and -A=D- are not -N=N-;
R3 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-Ci-
Cόalkoxy;
R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo- Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen;
R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
2. The compound according to claim 1 wherein R1 is Ci-Cόalkyl, halo-Ci-Cόalkyl, C3- Cecycloalkyl, halo-Q-Cscycloalkyl or tri-Ci-Cόalkylsilyl.
3. The compound according to claim 1 wherein R2 is a group (a).
4. The compound according to claim 1 wherein R is a group (b).
5. The compound according to claim 1 wherein
R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl; R2 is hydrogen or a group
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cgcycloalkyl, OH or halo-Ci-Cόalkoxy;
R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3- Cgcycloalkyl, OH or halo-Ci-C6alkoxy;
X is CR12 or N; Y is CH or N; wherein X and Y are not N at the same time; R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy; R5 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy; R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10; B is CR11 or N; D is CR3 or N; R3 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-Q-
Cόalkoxy; R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen; R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo- Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
6. The compound according to claim 1 wherein
R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl; R2 is hydrogen or a group
R6 and R7 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cgcycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cgcycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N;
Y is CH or N; wherein X and Y are not N at the same time;
R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy;
R5 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo- Ci-Cόalkoxy;
R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5 and R11 is not hydrogen; A is N; B is CR11; D is CR3;
R3 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-Ci-
Cόalkoxy; R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Q-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
7. The compound according to claim 1 wherein R1 is Ci-C6alkyl, halo-Ci-C6alkyl, halo-Ci-C6alkoxy, C3-C8cycloalkyl, halo-C3-C8cyclo- alkyl or tri-Ci-C6alkylsilyl; R2 is hydrogen or a group
Cgcycloalkyl, OH or halo-Ci-Cόalkoxy; R8 and R9 are independently hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, C3-
Cgcycloalkyl, OH or halo-Ci-Cόalkoxy; X is CR12 or N; Y is CH or N; wherein X and Y are not N at the same time; R12 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy; R5 is hydrogen, Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy; R4 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy when at least one of R3, R5, R10 and R11 is not hydrogen; A is CR10; B is CR11 or N; D is CR3; R3 is hydrogen, Ci-C6alkyl, halo-Ci-C6alkyl, halogen, C3-C8cycloalkyl, OH or halo-Ci-
Cόalkoxy; R10 is hydrogen, or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo-
Ci-Cόalkoxy, when at least one of R3, R4, R5 and R11 is not hydrogen; R11 is hydrogen or is Ci-Cόalkyl, halo-Ci-Cόalkyl, halogen, Cs-Cscycloalkyl, OH or halo- Ci-Cόalkoxy, when at least two of R3, R4, R5 and R10 are not hydrogen; wherein at least two of R3, R4, R5, R10 and R11 are not hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
8. The compound according to claim 1 wherein R1 is Ci-C6alkyl; R2 is a group
R12 is hydrogen, halogen or C3-Cgcycloalkyl; R5 is hydrogen or halogen;
R4 is Ci-C6alkyl, halo-Ci-C6alkyl or halogen; A is CR10; B is CR11 or N; D is CR3;
R3 is hydrogen;
R10 is halo-Ci-Cόalkyl or halogen; R11 is hydrogen; and n is 1, 2 or 3; and pharmaceutically acceptable salts thereof.
9. A process for the production of a compound of formula I according to claim 1 which process comprises reacting an acid derivative, a compound of formula II
ONa, OK or halogen, with a secondary amine derivative, a compound of formula III
10. Pharmaceutical compositions comprising a compound according to any one of claims 1 to 8 as well as a pharmaceutically acceptable carrier and/or adjuvant.
11. Pharmaceutical compositions according to claim 10 for the treatment and/or prophylaxis of diseases which are mediated by CETP.
12. Compounds according to any one of claims 1 to 8 for use as therapeutically active substances.
13. Compounds according to any one of claims 1 to 8 for use as therapeutically active substances for the treatment and/or prophylaxis of diseases which are mediated by CETP.
14. A method for the treatment and/or prophylaxis of diseases which are mediated by CETP, which method comprises administering a compound according to any one of claims 1 to 8 to a human bein 1gO or animal.
15. The use of compounds according to any one of claims 1 to 8 for the preparation of a medicament for the treatment and/or prophylaxis of diseases which are mediated by CETP.
16. The novel compounds, processes and methods as well as the use of such compounds substantially as described herein before.
Priority Applications (17)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| SI200731088T SI1984322T1 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| NZ570006A NZ570006A (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| CA2637765A CA2637765C (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| HRP20121009TT HRP20121009T1 (en) | 2006-02-07 | 2007-01-29 | BENZAMIDA I HETEROARENA DERIVATIVES |
| EP07712126A EP1984322B1 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| UAA200810888A UA90786C2 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| RS20120572A RS52612B (en) | 2006-02-07 | 2007-01-29 | BENZAMIDA I HETEROARENA DERIVATIVES |
| DK07712126.7T DK1984322T3 (en) | 2006-02-07 | 2007-01-29 | BENZAMIDE AND HEATER BODY DERIVATIVES |
| KR1020087019247A KR101124930B1 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| PL07712126T PL1984322T3 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| ES07712126T ES2392874T3 (en) | 2006-02-07 | 2007-01-29 | Derivatives of benzamides and heteroarenos |
| JP2008553710A JP5184376B2 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| CN2007800048032A CN101379022B (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| AU2007213831A AU2007213831B2 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
| BRPI0707703-3A BRPI0707703A2 (en) | 2006-02-07 | 2007-01-29 | benzamide and heteroarene derivatives |
| IL192845A IL192845A (en) | 2006-02-07 | 2008-07-16 | Benzamide and heteroarene derivatives, process for their preparation and pharmaceutical compositions comprising them |
| NO20083434A NO20083434L (en) | 2006-02-07 | 2008-08-05 | Benzamide and heteroaren derivatives |
Applications Claiming Priority (2)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| EP06101370 | 2006-02-07 | ||
| EP06101370.2 | 2006-02-07 |
Publications (1)
| Publication Number | Publication Date |
|---|---|
| WO2007090748A1 true WO2007090748A1 (en) | 2007-08-16 |
Family
ID=37898509
Family Applications (1)
| Application Number | Title | Priority Date | Filing Date |
|---|---|---|---|
| PCT/EP2007/050811 Ceased WO2007090748A1 (en) | 2006-02-07 | 2007-01-29 | Benzamide and heteroarene derivatives |
Country Status (28)
| Country | Link |
|---|---|
| US (1) | US7745477B2 (en) |
| EP (1) | EP1984322B1 (en) |
| JP (2) | JP5184376B2 (en) |
| KR (1) | KR101124930B1 (en) |
| CN (1) | CN101379022B (en) |
| AR (1) | AR059314A1 (en) |
| AU (1) | AU2007213831B2 (en) |
| BR (1) | BRPI0707703A2 (en) |
| CA (1) | CA2637765C (en) |
| CR (1) | CR10148A (en) |
| CY (1) | CY1113639T1 (en) |
| DK (1) | DK1984322T3 (en) |
| EC (1) | ECSP088666A (en) |
| ES (1) | ES2392874T3 (en) |
| HR (1) | HRP20121009T1 (en) |
| IL (1) | IL192845A (en) |
| MA (1) | MA30231B1 (en) |
| MY (1) | MY141794A (en) |
| NO (1) | NO20083434L (en) |
| NZ (1) | NZ570006A (en) |
| PL (1) | PL1984322T3 (en) |
| PT (1) | PT1984322E (en) |
| RS (1) | RS52612B (en) |
| RU (1) | RU2397976C2 (en) |
| SI (1) | SI1984322T1 (en) |
| TW (1) | TWI337992B (en) |
| UA (1) | UA90786C2 (en) |
| WO (1) | WO2007090748A1 (en) |
Cited By (22)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| WO2011112662A1 (en) | 2010-03-10 | 2011-09-15 | Incyte Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| WO2011157670A2 (en) | 2010-06-18 | 2011-12-22 | F. Hoffmann-La Roche Ag | Novel process |
| WO2012068450A1 (en) | 2010-11-19 | 2012-05-24 | Incyte Corporation | Cyclobutyl substituted pyrrolopyridine and pyrrolopyrimidine derivatives as jak inhibitors |
| US8691807B2 (en) | 2011-06-20 | 2014-04-08 | Incyte Corporation | Azetidinyl phenyl, pyridyl or pyrazinyl carboxamide derivatives as JAK inhibitors |
| US8722693B2 (en) | 2007-06-13 | 2014-05-13 | Incyte Corporation | Salts of the Janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US8933086B2 (en) | 2005-12-13 | 2015-01-13 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-B]pyridines and pyrrolo[2,3-B]pyrimidines as Janus kinase inhibitors |
| US8987443B2 (en) | 2013-03-06 | 2015-03-24 | Incyte Corporation | Processes and intermediates for making a JAK inhibitor |
| US9034884B2 (en) | 2010-11-19 | 2015-05-19 | Incyte Corporation | Heterocyclic-substituted pyrrolopyridines and pyrrolopyrimidines as JAK inhibitors |
| US9193733B2 (en) | 2012-05-18 | 2015-11-24 | Incyte Holdings Corporation | Piperidinylcyclobutyl substituted pyrrolopyridine and pyrrolopyrimidine derivatives as JAK inhibitors |
| US9216984B2 (en) | 2009-05-22 | 2015-12-22 | Incyte Corporation | 3-[4-(7H-pyrrolo[2,3-D]pyrimidin-4-yl)-1H-pyrazol-1-yl]octane—or heptane-nitrile as JAK inhibitors |
| US9249145B2 (en) | 2009-09-01 | 2016-02-02 | Incyte Holdings Corporation | Heterocyclic derivatives of pyrazol-4-yl-pyrrolo[2,3-d]pyrimidines as janus kinase inhibitors |
| US9334274B2 (en) | 2009-05-22 | 2016-05-10 | Incyte Holdings Corporation | N-(hetero)aryl-pyrrolidine derivatives of pyrazol-4-yl-pyrrolo[2,3-d]pyrimidines and pyrrol-3-yl-pyrrolo[2,3-d]pyrimidines as janus kinase inhibitors |
| US9359358B2 (en) | 2011-08-18 | 2016-06-07 | Incyte Holdings Corporation | Cyclohexyl azetidine derivatives as JAK inhibitors |
| US9487521B2 (en) | 2011-09-07 | 2016-11-08 | Incyte Holdings Corporation | Processes and intermediates for making a JAK inhibitor |
| US9498467B2 (en) | 2014-05-30 | 2016-11-22 | Incyte Corporation | Treatment of chronic neutrophilic leukemia (CNL) and atypical chronic myeloid leukemia (aCML) by inhibitors of JAK1 |
| US9655854B2 (en) | 2013-08-07 | 2017-05-23 | Incyte Corporation | Sustained release dosage forms for a JAK1 inhibitor |
| US10166191B2 (en) | 2012-11-15 | 2019-01-01 | Incyte Corporation | Sustained-release dosage forms of ruxolitinib |
| US10596161B2 (en) | 2017-12-08 | 2020-03-24 | Incyte Corporation | Low dose combination therapy for treatment of myeloproliferative neoplasms |
| US10758543B2 (en) | 2010-05-21 | 2020-09-01 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| US10899736B2 (en) | 2018-01-30 | 2021-01-26 | Incyte Corporation | Processes and intermediates for making a JAK inhibitor |
| US11304949B2 (en) | 2018-03-30 | 2022-04-19 | Incyte Corporation | Treatment of hidradenitis suppurativa using JAK inhibitors |
| US11833155B2 (en) | 2020-06-03 | 2023-12-05 | Incyte Corporation | Combination therapy for treatment of myeloproliferative neoplasms |
Families Citing this family (31)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| DE102004031323A1 (en) * | 2004-06-29 | 2006-01-19 | Bayer Cropscience Ag | Substituted Pyridazincarboxamide and derivatives thereof |
| US7745477B2 (en) * | 2006-02-07 | 2010-06-29 | Hoffman-La Roche Inc. | Heteroaryl and benzyl amide compounds |
| EP2025674A1 (en) | 2007-08-15 | 2009-02-18 | sanofi-aventis | Substituted tetra hydro naphthalines, method for their manufacture and their use as drugs |
| WO2009097995A1 (en) * | 2008-02-07 | 2009-08-13 | Sanofi-Aventis | Novel phenyl-substituted imidazolidines, method for the production thereof, medicaments containing said compounds and use thereof |
| JP5670325B2 (en) * | 2008-06-19 | 2015-02-18 | エックスカバリー ホールディング カンパニー エルエルシー | Substituted pyridazine carboxamide compounds as kinase inhibitor compounds |
| SG10201402867TA (en) | 2009-07-02 | 2014-08-28 | Sanofi Sa | Novel (6-oxo-1, 6-dihydro-pyrimidin-2-yl)-amide derivatives, preparation thereof, and pharmaceutical use thereof as akt(pkb) phosphorylation inhibitors |
| EP2582709B1 (en) | 2010-06-18 | 2018-01-24 | Sanofi | Azolopyridin-3-one derivatives as inhibitors of lipases and phospholipases |
| CN103003247B (en) | 2010-07-21 | 2015-06-10 | 拜耳知识产权有限责任公司 | 4-(4-haloalkyl-3-thiobenzoyl)pyrazoles and use thereof as herbicides |
| WO2012010575A1 (en) | 2010-07-21 | 2012-01-26 | Bayer Cropscience Ag | (4-halogenalkyl-3-thiobenzoyl)cyclohexanediones and use thereof as herbicides |
| WO2012120056A1 (en) | 2011-03-08 | 2012-09-13 | Sanofi | Tetrasubstituted oxathiazine derivatives, method for producing them, their use as medicine and drug containing said derivatives and the use thereof |
| US8828994B2 (en) | 2011-03-08 | 2014-09-09 | Sanofi | Di- and tri-substituted oxathiazine derivatives, method for the production thereof, use thereof as medicine and drug containing said derivatives and use thereof |
| EP2683704B1 (en) | 2011-03-08 | 2014-12-17 | Sanofi | Branched oxathiazine derivatives, method for the production thereof, use thereof as medicine and drug containing said derivatives and use thereof |
| EP2683699B1 (en) | 2011-03-08 | 2015-06-24 | Sanofi | Di- and tri-substituted oxathiazine derivates, method for the production thereof, use thereof as medicine and drug containing said derivatives and use thereof |
| EP2766349B1 (en) | 2011-03-08 | 2016-06-01 | Sanofi | Oxathiazine derivatives substituted with carbocycles or heterocycles, method for producing same, drugs containing said compounds, and use thereof |
| UY34200A (en) | 2011-07-21 | 2013-02-28 | Bayer Ip Gmbh | 3- (FLUOROVINIL) PIRAZOLES AND ITS USE |
| CN104797569A (en) | 2012-09-21 | 2015-07-22 | 百时美施贵宝公司 | Substituted 1,5-benzodiazepinone compounds |
| US9481650B2 (en) * | 2012-11-16 | 2016-11-01 | Hoffmann La Roche Inc. | Process for the preparation of 2-trifluoromethyl isonicotinic acid and esters |
| WO2015052104A1 (en) * | 2013-10-08 | 2015-04-16 | F. Hoffmann-La Roche Ag | Use of n-(4-tert-butylbenzyl)-3-chloro-n-[2-(4-chloro-3-ethyl-phenyl)-ethyl]-2-fluoro- 5-trifluoromethyl-benzamide for the treatment of eye diseases |
| JO3705B1 (en) | 2014-11-26 | 2021-01-31 | Bayer Pharma AG | Novel substituted indazoles, processes for preparation thereof, pharmaceutical preparations comprising them and use thereof for production of medicaments |
| EP3195865A1 (en) | 2016-01-25 | 2017-07-26 | Bayer Pharma Aktiengesellschaft | Combinations of inhibitors of irak4 with inhibitors of btk |
| TW201701879A (en) | 2015-04-30 | 2017-01-16 | 拜耳製藥公司 | Combinations of IRAK4 inhibitors |
| WO2017148902A1 (en) | 2016-03-03 | 2017-09-08 | Bayer Pharma Aktiengesellschaft | New 2-substituted indazoles, methods for producing same, pharmaceutical preparations that contain same, and use of same to produce drugs |
| EP3219329A1 (en) | 2016-03-17 | 2017-09-20 | Bayer Pharma Aktiengesellschaft | Combinations of copanlisib |
| WO2017207385A1 (en) | 2016-05-31 | 2017-12-07 | Bayer Pharma Aktiengesellschaft | Substituted 3-methylindazoles, methods for the production thereof, pharmaceutical preparations containing same, and use thereof for the production of medicaments |
| WO2017207340A1 (en) | 2016-05-31 | 2017-12-07 | Bayer Pharma Aktiengesellschaft | Novel substituted benzimidazole, methods for the production thereof, pharmaceutical preparations containing same, and use thereof to produce medicaments |
| SG10202011653WA (en) | 2016-06-01 | 2020-12-30 | Bayer Pharma AG | Use of 2-substituted indazoles for the treatment and prophylaxis of autoimmune diseases |
| MX394560B (en) | 2016-06-01 | 2025-03-24 | Bayer Pharma AG | USE OF SUBSTITUTED INDAZOLES FOR THE TREATMENT AND PREVENTION OF DISEASES IN ANIMALS. |
| WO2018060174A1 (en) | 2016-09-29 | 2018-04-05 | Bayer Pharma Aktiengesellschaft | Substituted benzimidazoles, pharmaceutical preparations containing same, and use of same to produce drugs |
| WO2020179859A1 (en) | 2019-03-06 | 2020-09-10 | 第一三共株式会社 | Pyrrolopyrazole derivative |
| KR20230017217A (en) * | 2020-05-27 | 2023-02-03 | 콘스텔레이션 파마슈티칼스, 인크. | Substituted benzamides as modulators of TREX1 |
| WO2025231630A1 (en) * | 2024-05-08 | 2025-11-13 | Sironax (Beijing) Co., Ltd. | Nampt modulators, preparations, and uses thereof |
Citations (2)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| WO2005100298A1 (en) * | 2004-04-13 | 2005-10-27 | Merck & Co., Inc. | Cetp inhibitors |
| WO2006013048A1 (en) * | 2004-08-05 | 2006-02-09 | F.Hoffmann-La Roche Ag | Indole, indazole or indoline derivatives |
Family Cites Families (9)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| WO1992020645A1 (en) * | 1991-05-20 | 1992-11-26 | Tsumura & Co. | Phellodendrine analogs and allergy type iv suppressor containing the same as active ingredient |
| US6858637B2 (en) * | 2002-03-28 | 2005-02-22 | Neurogen Corporation | Substituted biaryl amides as C5a receptor modulators |
| US7300917B2 (en) * | 2002-06-26 | 2007-11-27 | Ono Pharmaceuticals Co., Ltd. | Remedy for chronic disease |
| US7820682B2 (en) * | 2002-10-03 | 2010-10-26 | Ono Pharmaceutical Co., Ltd. | LPA receptor antagonist |
| JP2006521344A (en) * | 2003-03-28 | 2006-09-21 | ファイザー・プロダクツ・インク | 1,2,4-substituted 1,2,3,4-tetrahydro- and 1,2-dihydro-quinoline and 1,2,3,4 as CETP inhibitors for the treatment of atherosclerosis and obesity -Tetrahydro-quinoxaline derivatives |
| WO2004096213A1 (en) * | 2003-05-01 | 2004-11-11 | F. Hoffmann-La Roche Ag | Imidazolin-2-ylaminophenyl amides as ip antagonists |
| JP4793692B2 (en) | 2004-04-26 | 2011-10-12 | 小野薬品工業株式会社 | Novel BLT2-mediated diseases, BLT2-binding agents and compounds |
| US7745477B2 (en) * | 2006-02-07 | 2010-06-29 | Hoffman-La Roche Inc. | Heteroaryl and benzyl amide compounds |
| US7572823B2 (en) * | 2006-02-07 | 2009-08-11 | Hoffmann-La Roche Inc. | Heteroaryl carboxamide compounds |
-
2007
- 2007-01-25 US US11/698,221 patent/US7745477B2/en not_active Expired - Fee Related
- 2007-01-29 NZ NZ570006A patent/NZ570006A/en not_active IP Right Cessation
- 2007-01-29 BR BRPI0707703-3A patent/BRPI0707703A2/en not_active IP Right Cessation
- 2007-01-29 EP EP07712126A patent/EP1984322B1/en active Active
- 2007-01-29 DK DK07712126.7T patent/DK1984322T3/en active
- 2007-01-29 CN CN2007800048032A patent/CN101379022B/en not_active Expired - Fee Related
- 2007-01-29 ES ES07712126T patent/ES2392874T3/en active Active
- 2007-01-29 UA UAA200810888A patent/UA90786C2/en unknown
- 2007-01-29 JP JP2008553710A patent/JP5184376B2/en not_active Expired - Fee Related
- 2007-01-29 AU AU2007213831A patent/AU2007213831B2/en not_active Ceased
- 2007-01-29 PT PT77121267T patent/PT1984322E/en unknown
- 2007-01-29 PL PL07712126T patent/PL1984322T3/en unknown
- 2007-01-29 RS RS20120572A patent/RS52612B/en unknown
- 2007-01-29 SI SI200731088T patent/SI1984322T1/en unknown
- 2007-01-29 HR HRP20121009TT patent/HRP20121009T1/en unknown
- 2007-01-29 WO PCT/EP2007/050811 patent/WO2007090748A1/en not_active Ceased
- 2007-01-29 KR KR1020087019247A patent/KR101124930B1/en not_active Expired - Fee Related
- 2007-01-29 CA CA2637765A patent/CA2637765C/en not_active Expired - Fee Related
- 2007-01-29 RU RU2008136072/04A patent/RU2397976C2/en not_active IP Right Cessation
- 2007-02-05 AR ARP070100464A patent/AR059314A1/en not_active Application Discontinuation
- 2007-02-05 TW TW096104084A patent/TWI337992B/en not_active IP Right Cessation
-
2008
- 2008-07-16 IL IL192845A patent/IL192845A/en not_active IP Right Cessation
- 2008-07-16 CR CR10148A patent/CR10148A/en not_active IP Right Cessation
- 2008-08-05 NO NO20083434A patent/NO20083434L/en not_active Application Discontinuation
- 2008-08-05 MY MYPI20082962A patent/MY141794A/en unknown
- 2008-08-07 EC EC2008008666A patent/ECSP088666A/en unknown
- 2008-08-27 MA MA31197A patent/MA30231B1/en unknown
-
2012
- 2012-08-16 JP JP2012180374A patent/JP2012246303A/en active Pending
- 2012-12-03 CY CY20121101180T patent/CY1113639T1/en unknown
Patent Citations (2)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| WO2005100298A1 (en) * | 2004-04-13 | 2005-10-27 | Merck & Co., Inc. | Cetp inhibitors |
| WO2006013048A1 (en) * | 2004-08-05 | 2006-02-09 | F.Hoffmann-La Roche Ag | Indole, indazole or indoline derivatives |
Non-Patent Citations (1)
| Title |
|---|
| BRUCKNER D ET AL: "Dibenzodioxocinones-A new class of CETP inhibitors", BIOORGANIC & MEDICINAL CHEMISTRY LETTERS, OXFORD, GB, vol. 15, no. 15, 1 August 2005 (2005-08-01), pages 3611 - 3614, XP004969906, ISSN: 0960-894X * |
Cited By (76)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| US9814722B2 (en) | 2005-12-13 | 2017-11-14 | Incyte Holdings Corporation | Heteroaryl substituted pyrrolo[2,3-B] pyridines and pyrrolo[2,3-B] pyrimidines as janus kinase inhibitors |
| US9206187B2 (en) | 2005-12-13 | 2015-12-08 | Incyte Holdings Corporation | Heteroaryl substituted pyrrolo[2,3-B] pyridines and pyrrolo[2,3-B] pyrimidines as Janus kinase |
| US11331320B2 (en) | 2005-12-13 | 2022-05-17 | Incyte Holdings Corporation | Heteroaryl substituted pyrrolo[2,3-b]pyridines and pyrrolo[2,3-b]pyrimidines as Janus kinase inhibitors |
| US9662335B2 (en) | 2005-12-13 | 2017-05-30 | Incyte Holdings Corporation | Heteroaryl substituted pyrrolo[2,3-B] pyridines and pyrrolo[2,3-B] pyrimidines as janus kinase inhibitors |
| US10639310B2 (en) | 2005-12-13 | 2020-05-05 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-b]pyridines and pyrrolo[2,3-b]pyrimidines as Janus kinase inhibitors |
| US8946245B2 (en) | 2005-12-13 | 2015-02-03 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-b]pyridines and pyrrolo[2,3-b]pyrimidines as Janus kinase inhibitors |
| US9079912B2 (en) | 2005-12-13 | 2015-07-14 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-B] pyridines and pyrrolo[2,3-B] pyrimidines as Janus kinase inhibitors |
| US9974790B2 (en) | 2005-12-13 | 2018-05-22 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-B] pyridines and pyrrolo[2,3-B] pyrimidines as janus kinase inhibitors |
| US8933086B2 (en) | 2005-12-13 | 2015-01-13 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-B]pyridines and pyrrolo[2,3-B]pyrimidines as Janus kinase inhibitors |
| US10398699B2 (en) | 2005-12-13 | 2019-09-03 | Incyte Holdings Corporation | Heteroaryl substituted pyrrolo[2,3-b]pyridines and pyrrolo[2,3-b]pyrimidines as janus kinase inhibitors |
| US11744832B2 (en) | 2005-12-13 | 2023-09-05 | Incyte Corporation | Heteroaryl substituted pyrrolo[2,3-b]pyridines and pyrrolo[2,3-b]pyrimidines as Janus kinase inhibitors |
| US10016429B2 (en) | 2007-06-13 | 2018-07-10 | Incyte Corporation | Salts of the janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-D]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US10610530B2 (en) | 2007-06-13 | 2020-04-07 | Incyte Corporation | Salts of the Janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US8829013B1 (en) | 2007-06-13 | 2014-09-09 | Incyte Corporation | Salts of the Janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-D]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US8822481B1 (en) | 2007-06-13 | 2014-09-02 | Incyte Corporation | Salts of the janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-d] pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US9376439B2 (en) | 2007-06-13 | 2016-06-28 | Incyte Corporation | Salts of the janus kinase inhibitor (R)-3(4-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US8722693B2 (en) | 2007-06-13 | 2014-05-13 | Incyte Corporation | Salts of the Janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US11213528B2 (en) | 2007-06-13 | 2022-01-04 | Incyte Holdings Corporation | Salts of the janus kinase inhibitor (R)-3-(4-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)-1H-pyrazol-1-yl)-3-cyclopentylpropanenitrile |
| US9216984B2 (en) | 2009-05-22 | 2015-12-22 | Incyte Corporation | 3-[4-(7H-pyrrolo[2,3-D]pyrimidin-4-yl)-1H-pyrazol-1-yl]octane—or heptane-nitrile as JAK inhibitors |
| US9334274B2 (en) | 2009-05-22 | 2016-05-10 | Incyte Holdings Corporation | N-(hetero)aryl-pyrrolidine derivatives of pyrazol-4-yl-pyrrolo[2,3-d]pyrimidines and pyrrol-3-yl-pyrrolo[2,3-d]pyrimidines as janus kinase inhibitors |
| US9623029B2 (en) | 2009-05-22 | 2017-04-18 | Incyte Holdings Corporation | 3-[4-(7H-pyrrolo[2,3-d]pyrimidin-4-yl)-1H-pyrazol-1-yl]octane- or heptane-nitrile as JAK inhibitors |
| US9249145B2 (en) | 2009-09-01 | 2016-02-02 | Incyte Holdings Corporation | Heterocyclic derivatives of pyrazol-4-yl-pyrrolo[2,3-d]pyrimidines as janus kinase inhibitors |
| EP3354652A1 (en) | 2010-03-10 | 2018-08-01 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| US9999619B2 (en) | 2010-03-10 | 2018-06-19 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as JAK1 inhibitors |
| US9464088B2 (en) | 2010-03-10 | 2016-10-11 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as JAK1 inhibitors |
| EP4400172A2 (en) | 2010-03-10 | 2024-07-17 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| EP4036088A1 (en) | 2010-03-10 | 2022-08-03 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| US11285140B2 (en) | 2010-03-10 | 2022-03-29 | Incyte Corporation | Piperidin-4-yl azetidine derivatives as JAK1 inhibitors |
| EP3050882A1 (en) | 2010-03-10 | 2016-08-03 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| EP3715347A1 (en) | 2010-03-10 | 2020-09-30 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| US10695337B2 (en) | 2010-03-10 | 2020-06-30 | Incyte Holdings Corporation | Piperidin-4-yl azetidine derivatives as JAK1 inhibitors |
| WO2011112662A1 (en) | 2010-03-10 | 2011-09-15 | Incyte Corporation | Piperidin-4-yl azetidine derivatives as jak1 inhibitors |
| US10869870B2 (en) | 2010-05-21 | 2020-12-22 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| US11590136B2 (en) | 2010-05-21 | 2023-02-28 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| US11219624B2 (en) | 2010-05-21 | 2022-01-11 | Incyte Holdings Corporation | Topical formulation for a JAK inhibitor |
| US12564593B2 (en) | 2010-05-21 | 2026-03-03 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| US12544381B2 (en) | 2010-05-21 | 2026-02-10 | Incyte Corporation | Topical formulation for JAK inhibitor |
| US12226419B2 (en) | 2010-05-21 | 2025-02-18 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| US11571425B2 (en) | 2010-05-21 | 2023-02-07 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| US10758543B2 (en) | 2010-05-21 | 2020-09-01 | Incyte Corporation | Topical formulation for a JAK inhibitor |
| WO2011157670A2 (en) | 2010-06-18 | 2011-12-22 | F. Hoffmann-La Roche Ag | Novel process |
| WO2011157670A3 (en) * | 2010-06-18 | 2012-04-19 | F. Hoffmann-La Roche Ag | Process for the preparation of benzamide derivatives |
| US9034884B2 (en) | 2010-11-19 | 2015-05-19 | Incyte Corporation | Heterocyclic-substituted pyrrolopyridines and pyrrolopyrimidines as JAK inhibitors |
| US8933085B2 (en) | 2010-11-19 | 2015-01-13 | Incyte Corporation | Cyclobutyl substituted pyrrolopyridine and pyrrolopyrimidine derivatives as JAK inhibitors |
| WO2012068450A1 (en) | 2010-11-19 | 2012-05-24 | Incyte Corporation | Cyclobutyl substituted pyrrolopyridine and pyrrolopyrimidine derivatives as jak inhibitors |
| US10640506B2 (en) | 2010-11-19 | 2020-05-05 | Incyte Holdings Corporation | Cyclobutyl substituted pyrrolopyridine and pyrrolopyrimidines derivatives as JAK inhibitors |
| US11214573B2 (en) | 2011-06-20 | 2022-01-04 | Incyte Holdings Corporation | Azetidinyl phenyl, pyridyl or pyrazinyl carboxamide derivatives as JAK inhibitors |
| US9611269B2 (en) | 2011-06-20 | 2017-04-04 | Incyte Corporation | Azetidinyl phenyl, pyridyl or pyrazinyl carboxamide derivatives as JAK inhibitors |
| US9023840B2 (en) | 2011-06-20 | 2015-05-05 | Incyte Corporation | Azetidinyl phenyl, pyridyl or pyrazinyl carboxamide derivatives as JAK inhibitors |
| US10513522B2 (en) | 2011-06-20 | 2019-12-24 | Incyte Corporation | Azetidinyl phenyl, pyridyl or pyrazinyl carboxamide derivatives as JAK inhibitors |
| US8691807B2 (en) | 2011-06-20 | 2014-04-08 | Incyte Corporation | Azetidinyl phenyl, pyridyl or pyrazinyl carboxamide derivatives as JAK inhibitors |
| US9359358B2 (en) | 2011-08-18 | 2016-06-07 | Incyte Holdings Corporation | Cyclohexyl azetidine derivatives as JAK inhibitors |
| US9718834B2 (en) | 2011-09-07 | 2017-08-01 | Incyte Corporation | Processes and intermediates for making a JAK inhibitor |
| US9487521B2 (en) | 2011-09-07 | 2016-11-08 | Incyte Holdings Corporation | Processes and intermediates for making a JAK inhibitor |
| US9193733B2 (en) | 2012-05-18 | 2015-11-24 | Incyte Holdings Corporation | Piperidinylcyclobutyl substituted pyrrolopyridine and pyrrolopyrimidine derivatives as JAK inhibitors |
| US11896717B2 (en) | 2012-11-15 | 2024-02-13 | Incyte Holdings Corporation | Sustained-release dosage forms of ruxolitinib |
| US11576864B2 (en) | 2012-11-15 | 2023-02-14 | Incyte Corporation | Sustained-release dosage forms of ruxolitinib |
| US10874616B2 (en) | 2012-11-15 | 2020-12-29 | Incyte Corporation | Sustained-release dosage forms of ruxolitinib |
| US10166191B2 (en) | 2012-11-15 | 2019-01-01 | Incyte Corporation | Sustained-release dosage forms of ruxolitinib |
| US11576865B2 (en) | 2012-11-15 | 2023-02-14 | Incyte Corporation | Sustained-release dosage forms of ruxolitinib |
| US11337927B2 (en) | 2012-11-15 | 2022-05-24 | Incyte Holdings Corporation | Sustained-release dosage forms of ruxolitinib |
| US9714233B2 (en) | 2013-03-06 | 2017-07-25 | Incyte Corporation | Processes and intermediates for making a JAK inhibitor |
| US9221845B2 (en) | 2013-03-06 | 2015-12-29 | Incyte Holdings Corporation | Processes and intermediates for making a JAK inhibitor |
| US8987443B2 (en) | 2013-03-06 | 2015-03-24 | Incyte Corporation | Processes and intermediates for making a JAK inhibitor |
| US10561616B2 (en) | 2013-08-07 | 2020-02-18 | Incyte Corporation | Sustained release dosage forms for a JAK1 inhibitor |
| US11045421B2 (en) | 2013-08-07 | 2021-06-29 | Incyte Corporation | Sustained release dosage forms for a JAK1 inhibitor |
| US12151026B2 (en) | 2013-08-07 | 2024-11-26 | Incyte Corporation | Sustained release dosage forms for a JAK1 inhibitor |
| US9655854B2 (en) | 2013-08-07 | 2017-05-23 | Incyte Corporation | Sustained release dosage forms for a JAK1 inhibitor |
| US9498467B2 (en) | 2014-05-30 | 2016-11-22 | Incyte Corporation | Treatment of chronic neutrophilic leukemia (CNL) and atypical chronic myeloid leukemia (aCML) by inhibitors of JAK1 |
| US11278541B2 (en) | 2017-12-08 | 2022-03-22 | Incyte Corporation | Low dose combination therapy for treatment of myeloproliferative neoplasms |
| US10596161B2 (en) | 2017-12-08 | 2020-03-24 | Incyte Corporation | Low dose combination therapy for treatment of myeloproliferative neoplasms |
| US10899736B2 (en) | 2018-01-30 | 2021-01-26 | Incyte Corporation | Processes and intermediates for making a JAK inhibitor |
| US11304949B2 (en) | 2018-03-30 | 2022-04-19 | Incyte Corporation | Treatment of hidradenitis suppurativa using JAK inhibitors |
| US12280054B2 (en) | 2018-03-30 | 2025-04-22 | Incyte Corporation | Treatment of hidradenitis suppurativa using JAK inhibitors |
| US11833155B2 (en) | 2020-06-03 | 2023-12-05 | Incyte Corporation | Combination therapy for treatment of myeloproliferative neoplasms |
| US12440495B2 (en) | 2020-06-03 | 2025-10-14 | Incyte Corporation | Combination therapy for treatment of myeloproliferative neoplasms |
Also Published As
Similar Documents
| Publication | Publication Date | Title |
|---|---|---|
| WO2007090748A1 (en) | Benzamide and heteroarene derivatives | |
| CA2637771C (en) | Anthranilamide/2-amino-heteroarene carboxamide derivatives | |
| US7674815B2 (en) | Heteroaryl and benzyl amide compounds | |
| US7259183B2 (en) | Indole, indazole and indoline derivatives as CETP inhibitors | |
| IL154079A (en) | 4-phenyl-pyridine derivatives as neurokinin-1 receptor antagonists | |
| EP1984364A1 (en) | Heterobicyclic amide derivatives | |
| MX2008009834A (en) | Benzamide and heteroarene derivatives | |
| AU2004208483A1 (en) | Crystalline modifications of 2-(3,5-bis-trifluoromethyl-phenyl)-N-[6-(1,1-dioxo-1lamda6-thiomorpholin-4-yl)-4-(4-fluoro-2-methyl-phenyl)-pyridin-3-yl]-N-methyl-isobutyramide | |
| EP1856052A2 (en) | Nk1 antagonists | |
| HK1129366B (en) | Benzamide and heteroarene derivatives | |
| HK1129366A (en) | Benzamide and heteroarene derivatives |
Legal Events
| Date | Code | Title | Description |
|---|---|---|---|
| 121 | Ep: the epo has been informed by wipo that ep was designated in this application | ||
| DPE2 | Request for preliminary examination filed before expiration of 19th month from priority date (pct application filed from 20040101) | ||
| WWE | Wipo information: entry into national phase |
Ref document number: 2007712126 Country of ref document: EP |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 192845 Country of ref document: IL Ref document number: CR2008-010148 Country of ref document: CR |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 2637765 Country of ref document: CA |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 570006 Country of ref document: NZ |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 08077501 Country of ref document: CO |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 2007213831 Country of ref document: AU |
|
| WWE | Wipo information: entry into national phase |
Ref document number: MX/a/2008/009834 Country of ref document: MX |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 2008081324 Country of ref document: EG Ref document number: 12008501774 Country of ref document: PH |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 4106/CHENP/2008 Country of ref document: IN Ref document number: PI 20082962 Country of ref document: MY |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 1020087019247 Country of ref document: KR |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 2008553710 Country of ref document: JP Ref document number: 200780004803.2 Country of ref document: CN |
|
| NENP | Non-entry into the national phase |
Ref country code: DE |
|
| WWP | Wipo information: published in national office |
Ref document number: 2007213831 Country of ref document: AU |
|
| ENP | Entry into the national phase |
Ref document number: 2008136072 Country of ref document: RU Kind code of ref document: A |
|
| ENP | Entry into the national phase |
Ref document number: PI0707703 Country of ref document: BR Kind code of ref document: A2 Effective date: 20080807 |
|
| DPE2 | Request for preliminary examination filed before expiration of 19th month from priority date (pct application filed from 20040101) | ||
| WWE | Wipo information: entry into national phase |
Ref document number: P-2012/0572 Country of ref document: RS |
